W hen you order parts, please m ake a photocopy of this page
and fill the num ber of the parts in the "Order" colum n.
INDOOR U NIT
PARTS LIST
Ref.
No.
Description
Ord.
Q`ty
34 Capacitor (Fan Motor) 9900089061 9900089061
63 9312172061 9312172023
65 Flow Control Panel-Z 9306058012 9306058012
69 Louver-A 9306055028 9306055028
74 Filter 9305444014 9305444014
108 Base 9309755062 9309755062
109 Casing 9306052027 9306052027
122 Shaft Holder-B 9303066010 9303066010
127 Drain Hose Assy 9305550029 9305550029
146 Evaporator Assy 9308555069 9308555069
151 Control Box 9330007017 9330007017
158 Connecting Pipe Assy 9306416010 9306699000
164 Fan Motor Assy-IN 9601172017 9601172017
169 Cross-Flow Fan Assy 9305435012 9305435012
178 Motor Cushion-M 9601302018 9601302018
184 Thermistor Spring 313728262708 313728262708
185 Wire Clamp 9330015012 9330015012
188 Power Cord Assy 9702595043 9702595043
196 Clamp SKB-150 313035356905 313035356905
233 Power Transformer 9701803026 9701803026
235 Thermistor Assy-Pipe 9702039059 9702039059
236 Controller PCB Assy 9704865038 9704865014
240 Remote Control Unit 9312058020 9312058020
Part No.
Ref.
No.
Description
Ord.
Q`ty
401 Wall Hook Bracket 9304358008 9304358008
440 Flow Control Panel-U 9306057015 9306057015
466 Clamp NK-4N 313714328805 313714328805
522-1 Gear-A 9306062002 9306062002
523 Gear Bracket 9306407001 9306407001
652-1 Thermistor Holder Pipe 313714262805 313714262805
668 Screw w/Washer 313681304205 313681304205
687 Earth Terminal 9330012011 9330012011
759 Intake
Grille-B
9330002012 9330002012
764 Drain Cap Assy 9304150008 9304150008
777 9306755010 9306755010
815 Terminal 9900040048 9900040048
850 Window (Receiver) 9330003019 9330003019
872 Indicator Case 9330009011 9330009011
873 Lamp Cover 9330014015 9330014015
874 Control Box Cover 9330008014 9330008014
PCB (Power and Indicator) 9704870018 9704870018
876 Step Motor 9900139018 9900139018
Part No.
ASH9RSJCW
ASH9RSJCW ASH12RSJCW ASH9RSJCW ASH12RSJCW
ASH12RSJCW
281 Clamp Metal (Pipe) 9306063009 9306063009
283 Bushing-A 9303529010 9303529010
323 Louver-B 9306056025 9306056025
385
- 13 -
767-1 Bottom Cover-A 9330004016 9330004016
Clamper(Grille)
2004.02.18
Panel (Front) Total Assy
877
Face Panel (Front)-B 9330006034
9330006034
