Name and Shape
Part No.
ASH9RSJCW ASH12RSJCW
9304358008 9304358008
9312058020 9312058020
0600185534 0600185534
9308117007 9308117007
0700076046
0700076046
9303029015
9304536000
-------
Remote control
unit
Battery (penlight)
Cloth tape
Drain pipe
Seal A
(Including drain packing)
Tapping screw
( 4 x 25 )
Wall hook bracket
STANDARD ACCESSORIES
- 15 -
O
2003.07.04
9303029015
