General-Fujitsu AOHZ24LBT [24/27] Parts list
![General-Fujitsu AOHZ24LBT [24/27] Parts list](/views2/1804969/page24/bg18.png)
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
PARTS LIST
Ref.
No.
Description
AWHZ24LBC
Ord.
Q'ty
4 Open Panel Assy 9314405037
1 Air Filter 9313859015
3 Front Panel Total Assy 9313882112
5 Top Grill 9313848019
2 Dust Box Assy 9313884024
7 Under Cover 9313850029
9 Casing Assy 9313877040
10 Louver U Assy 9312243037
11 Louver U 9311993032
12 Louver Frame 9311994015
13 Spring EL 9312194001
14 Louver Z 9311996033
15 Spring F 9314143014
16 Diffuser U 9313856014
17 Diffuser Z 9313857011
18 Spring C 9314142017
19 Casing Cover F 9313839017
24 Louver Cam 9312000012
25 Tension A 9312197002
26 Spring Holder 9311999010
27 Gear A 9309994003
28 Drain Hose Assy 9314147012
29 Drain Cap Assy 9304150008
30 Evaporator Assy 9316068018
31 Evaporator Assy B 9312213023
32 Evaporator Assy D 9313584016
33 Joint Pipe Assy 9316065017
41 Crossflow Fan Assy 9312004010
42 Bearing C Assy 9306628017
43 Control Box 9312005017
44 Controll Cover 9312006014
23 Bushing-A
Part No.
9303529010
47 Cord Clamp 9302271002
48 Evaporator Holder R 9313833015
49 Evaporator Holder L 9313834012
50 Rear Bracket 9312416011
51 PCB Assy
(Controller + Indicator)
9707154054
52 Terminal 9900385019
53 Display Assy 9705808027
54 Fan Motor Assy 9601888017
56 Stepping Motor U 9703477010
57 Stepping Motor Z 9305780006
60 UV Unit Assy 9314153013
61 Remote Controller Assy 9314157035
62 Gear Box Assy 9313880019
--- Room Temp. Thermistor 9700801139
--- Pipe Temp. Thermistor 9702039042
--- Fuse 3A 0600376062
2006.10.31 23
