As shown in the above diagram,after running for 1 hour under refrigerating mode
and dehumidification mode,the setting temperature will increase 1
o
C;after another
1 hour,it will increase 1
o
C again,and after 6hours,it will cease;after running for
1 hour under heating mode, the setting temperature will decrease 2
o
C, after another
1 hour,it will decrease the 2
o
C again,and after 3 hours,it will increase 1
o
C,and after
other 3 hours,it will cease.
MODEL PCB The SW2 select “25”OR “35”
HSU-12HD03/R2 0010404012 35
HSU-09HD03/R2 0010404012 25
HSU-07HD03/R2 0010403257A 25
Haier air conditioner Edition: 1.0-061128
- 12-
