Haier HSU-12HA03/Z1 [7/32] Electrical control
![Haier HSU-12HA03/Z1 [7/32] Electrical control](/views2/1806494/page7/bg7.png)
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Function
Description of function
Cooling
Drying
Heating (heat pump type)
Emergency run
Test run
Anti-cold wind (heat pump type)
Fan speed adjustment
Timer switch
High load protection (heat pump type)
Anti-freezing of the indoor unit
Defrosting run (heat pump type)
Self trouble shooting
Over current protection(heat pump type)
Set temperature 16℃ 30℃æ
Set temperature 16℃-30℃¡æ
Set temperature 16℃-30℃¡æ
Over 23℃¡æ cooling and set 26℃¡
æ£℃»
less 23¡æ heating and set 23℃¡
æ
Set force cooling
-
When temperature of the heating pipe coil is low, low fan speed
or without airflow
When heating in high ambient temperature to protect
compressor
When heating in low ambient temperature to protect system
When heating in low ambient temperature to defrost for the
outdoor unit in order to make the system have a better efficiency
Auto, high, middle, low four level fan speeds
24hours timer on, timer off, on-off, off-on
Check the system trouble and give an alarm
When working in high power to protect system
Haier air conditioner Edition: 1.0-061128
3. Electrical control
1. Basic Function
- 7-
