Haier air conditioner Edition: 1.0-061120
- 5 -
2. Specification
Item
HSU-12HA03/Z1
Power PH, V, Hz 1, 220, 50
Climate Type T1
Starting Current A
Cooling Capacity W 3450
Rated Power W 1250
Rated Current A 6.0
Max Power W 1600
Max Current A 7.0
Cooling
EER W/W 2.70
Heating Capacity W 3650
Rated Power W 1280
Rated Current A 6.1
Max Power W 1650
Max Current A 7.1
Heating
COP W/W 2.85
Cooling
℃
14~21 Operating temp.
range
Heating
℃
12~19
H rpm 1290
M rpm 1150
Indoor fan Velocity
L rpm 1000
Outdoor fan Velocity rpm 1060
Indoor Air Volume (High) m
3
450
Max. pressure at warm side MPa 2.65
Moisture Removal 10
-3
m
3
/h 1.7
Indoor (H/M/L) dB(A) 44/40/37
Noise Level
Outdoor dB(A) 53
Net Kg 8.6
Indoor Weight
Gross Kg 10.6
Net Kg 32
Outdoor Weight
Gross Kg 34
Net mm 795*182*265
Indoor Dimension
Package mm 863*277*339
Net mm 700*250*430
Outdoor Dimension
Package mm 823*363*505
Manufacture RECHI
Type 48R313NL-5ESF
Compressor
Oil Charge CC -----
Type R22
Net Charge g 970
Refrigerant
Charge if over standard pipe
length
g/m 35
Unit
Model
