Knock-down drawingsKnock-down drawings
Knock-down drawings for indoor unit
Models:HSU-12RD03
NO.
Name of the
COMPOLENT
Specialized No. QTY.
Easily damaged
components(Y/N)
1
Front grille
001A1232303 1
2
Air filter
001A2400058 1
3 Front panel assy. 001A1232074 1
4 Flap 001A1232077 1
5 Drain pan assy. 001A0900107 1
6
Heat exchanger
0010703599 1
7 Bearing 001A0300005 1
8 Fan 0010202415 1
9 Rear case assy. 001A0100206 1
10 Mounting plate 001A1301216 1
11 Motor 001A3000052 1 Y
12 Tansformer 001A3800002 1 Y
13 PCB 0010402620 1 Y
14 Terminal block 001A4000091 1
15 PCB(receiver) 0010402242 1
16 Drain tube 001A1434039 1
17 Swing motor 001A3000072 1 Y
18 Remote controller 0010402639 1 Y
19 Drain tube 001A1434039 1
20
Air purifying assy.
001A2400059 1
21 Sensor 001A3900059 1 Y
