1.DESCRIPTION OF PRODUCTS & FEATURES
1.1. Products code explanation
H P U - 42 C V 03
Power supply type: 03 stands for 200-220V, 50Hz
Design sequence
C: cooling; H: heating
Cooling capacity: 42=42000BTU/h
U: single split unit
Product type : “B” stands for cassette type, “C” stands for
convertible type, ”D” stands for duct, “S” stands for split
type, ”P” stands for cabinet system, "E" stands for ceiling
concealed type.
Haier Brand Air Conditioner
1.2 Brief Introduction for T1、T2、T3 working condition
1.3 Operating Range of Air Conditioners
Temp. Mode Rated Maximum Minimum
DB ℃
27 32 15
Indoor
WB ℃
19 23 14
DB ℃
35 43 -5
Cooling
Outdoor
WB ℃
24 26 6
DB ℃
20 27 10
Indoor
WB ℃
14.5 --- --
DB ℃
7 23 -10
Heating
Outdoor
WB ℃
6 18 ---
Climate type
Type of Air
Conditioner
T1 T2 T3
Cooling Only
18 ℃~43℃ 10℃~35℃ 21℃~52℃
Heat pump
-7℃~43℃ -7℃~35℃ -7℃~52℃
Electricity Heating
~43℃ ~35℃ ~52℃
Commercial Air Conditioner Model: HPU-42CV03
HPU-42HV03
2
