REMOTE CONTROLLER OPERATION

When in use, put the signal transmission head directly to the receiver hole on the indoor unit.

The distance between the signal transmission head and the receiver hole should be within 7m

without any obstacle as well.

Don't throw the controller, prevent it from being damaged.

When electronic-started type fluorescent lamp or change-over type fluorescent lamp or wireless

telephone is installed in the room, the receiver is apt to be disturbed in receiving the signals so

the distance to the indoor unit should be shorter.

Loading of the battery

Load the batteries as illustrated.

2R-03 batteries, resetting key (cylinder)

Remove the battery cover :

Slightly press " " and push down the cover.

Load the battery :

Be sure that the loading is in line with the " + " / " - " pole request as

illustrated.

Put on the cover again

Confirmation indicator :

In disorderation, reload the batteries or load the new batteries

after 5mins.

Note :

Use two new same-typed batteries when loading.

If the remote controller can't run normally or doesn't work at all,

use a sharp pointed item to press the reset key.

Hint :

Remove the batteries in case unit won't be in usage for a long period.

If there is any display after taking-out just need to press reset key.

Remote controller's operation

TEMP

SWING

FAN

OFF

MODE

SLEEP

SET

CLOCK

TIMER

LOCK

RESET
