Domestic air conditioner
indoor temp.
'%:%
18/12
2686 2697 2707 2486 2496 2539 2389 2173
18/14
3169 3180 3247 2995 2958 2828 2716 2530
20/15
3651 3664 3677 3582 3420 3259 3123 2887
22/16
3597 3613 3630 3562 3387 3181 3042 2877
25/18
3544 3563 3582 3541 3354 3168 3045 2849
27/19
3805 3715 3765 3602 3500 3349 3226 3002
30/22
4082 3934 4122 3828 3698 3568 3396 3249
32/23
4182 3918 4128 3799 3742 3633 3505 3277
32/24
4261 3992 4206 3871 3813 3701 3570 3340
outdoor temp.(humidity 46%)
cooling value-temerature talbe
HSU-12HEA03/(BP) performance curves
HSU-09 12HEA03/(BP)
Capacity
