Haier HSU-09HEA03/(BP) [9/38] Dimensional drawings
![Haier HSU-09HEA03/(BP) [9/38] Dimensional drawings](/views2/1809670/page9/bg9.png)
HSU-09 12 HEA03/(BP)
8
795
265
795
265
5 Dimensional drawings
Indoor unit
HSU-09HEA03/(BP)
187
HSU-12HEA03/(BP)
Dimendional drawings
