Capacity
1 7
Domestic air conditioner
outdoor temp.
DB/WB
15
ć
20
ć
25
ć
-15
ć
1645 1572 1475
-5
ć
2484 2398 2275
5
ć
2886 2794 2669
7/6
ć
3399 3800 2928
15
ć
3900 3950 3700
20
ć
4200 4100 4000
25
ć
4700 4450 4200
indoor temp.(humidity 46%)
heating capacity and indoor/outdoor temp.curves
HSU-12HEA03/(BP) performance curves
KHDWLQJFDSDFLW\DQGLQGRRURXWGRRUWHPSFXUYHV
LQGRRUWHPSH'%:%
conoling capacity(w)
HSU-09 12HEA03/(BP)
15°C
20°C
25°C
