DRY function: Make dehumidifying in the room when the unit is working in the "DRY" mode
12 Hour timer: Use the timer function to set on,or off.
Easy clean design: The panel is easy to wash and the airflow vents can be detached without
any special tools for quick cleaning of the inside of the air conditioner
Intelligent air: With twin-blade technology ,the airflow can be adjusted not to blow directly to
human body,so preventing people from the air condintioner sympton
Anti-mold filter: Catches most small particles and remove unpleasant odors effectively
4 Fan setting: Slect the fan speed LO,MED,HI,AUTO
Domestic air conditioner
Specifications
HSU-0912HEA03/(BP)
Child lock: Avoid the child’s wrong operation on the remote controller.
