Haier HSU-12HEA03(BP) [6/8] Outdoor unit

Outdoor unit

1.Installation of Outdoor Unit

3.Connection

4.Atta

ching Drain-Elbow

2.Connection of pipes

Install according to

To bend a pipe, give the roundness as large as possible not to crush the pipe

Connecting the pipe of gas side first ma

kes working easier.

The max

vertical distance between the indoor unit and the outdoor unit is 5 m.

Use the same method on indoor unit

. Loosen the screws on terminal block and insert the plugs fully into

rminal block, then tighten the screws.

If wi

ring is not correct, proper operation can not be carried out and controller may be damaged.

If the drain-elbow is used, please attach it as

figure. (Note: Only for heat pump unit.)

awing for the installation of indoor and outdoor units

Inse

rt the cable according to terminal number in the same manner as the indoor unit.

Fix the ca

ble with a clamp.

Half union

Flare

nut

Spanner

Torque wrench

Outdoor unit

Forced fastening without careful centering

may damage the threads and cause a

leakage of ga

Be careful that matters, such as wastes of sands, etc. shall not enter the pipe.

Pipe Diameter ( )

Liquid side 6.35mm(1/4")

Gas side 9.52mm(3/8")

Fastening torque

18N.m

42N.m

Gas side 12.7mm(1/2")

50N.m

Liquid side 9.52mm(3/8")

40N.m
