Haier HSU-12HEA03(BP) [8/8] Correct incorrect
![Haier HSU-12HEA03(BP) [8/8] Correct incorrect](/views2/1809671/page8/bg8.png)
It becomes high midway.
The end is immersed
in
water.
It
waves. The gap with the ground
is too small
Less than 5cm
There is the bad smell
from a ditch
1.Power Source Installation
2.Cutting and Flaring
Work of Piping
3.On Drain
age
Che
ck for Installation and Test Run
Check Items for Test Run
The power source must be exclusively used for air conditioner. (Over I0A)
In the case of installing an air conditioner in a moist plac
e, please install an
ea
rth leakage breaker.
For installation in other places, use a circuit breaker as far as possible.
Pipe cutting is car
ried out with a pipe cutter and burs must be removed.
After inse
rting the flare nut, flaring work is carried out.
Please install the d
rain hose so as to be downward slope without fail.
Please don't do the d
rainage as shown below.
Please pour
water in the drain pan of the indoor unit, and confirm that drainage is
car
ried out surely to outdoor.
In case that the attached d
rain hose is in a room, please apply heat insulation
to it without
fail.
Please kindly
explain to our customers how to operate through the instruction manual.
Gas leak from pipe connecting?
Heat insulation of pipe connecting?
Are the connecting wi
rings of
indoor and outdoor fi
rmly inserted
to the te
rminal block?
Is the connecting wi
ring of indoor
and outdoor fi
rmly fixed?
Is d
rainage securely carried out?
Is the ea
rth line securely
connected?
Is the indoor unit securely fi
xed?
Is p
ower source voltage abided
by the code?
Is there a
ny noise?
Put che
ck mark in boxes
Is the lamp no
rmally lighting?
Are cooling and heating (when
in heat pump) per
formed normally?
Is the ope
ration of room temperature
regulator no
rmal?
8
Correct
Incorrect
Lean Damage of flare Crack Partial Too outside
Flare tooling die
A
Liquid side
Pipe diameter( )
Size A(mm)
6.35mm(1/4")
9.52mm(3/8")
0.8~1.5
1.0~1.8
Gas side
Gas side 12.7mm(1/2")
1.2~2.0
Liquid side
9.52mm(3/8")
1.0~1.8
