Sc&t HE20E [3/3] Caution

RJ45 Define:

Video Link (TIA/EIA-568-B)

1. Orange-white DATA0 +

2. Orange DATA0 -

3. Green-white DATA1 +

Caution:

1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone,

microwave, radio equipment, fluorescent lamp, high voltage power lines.

2. The cable must pull in straight to avoid any crosstalk interference and the transmission

stability.

3. This device HDBaseT port is not general Ethernet signal; do not connect with Network

devices to avoid damage.

4. IR transmitter do not put near from receiver to avoid mutual interference.

DB9(F)/3.5mm STEREO PHONE JACK x 1

Mounting Screw pack x 2 bags

DC5V 2Amp Power Adapter x 2 pcs

Specification:

Rev. A
