Dishwasher installation steps

●

1 Inst all the furniture door t o the o ute r doo r of th e dis hwasher u sing the bracket s

pr ovided. Re fer t o the temp late f or position ing of the b racket s.

2 Adjust the tension of the door springs by using anAllen key turning in a clockwise

m otion totig hten the le ft and right door springs. F ailure to d o this could cause d amage

to your dishwasher (Illustration 2)

3 C on ne c t th e inl e t hose t o t he c o l d w a t er supply

4 C onn ect t he dr ain ho se. Refer to dia gram (Figure 6 )

5 Connect the power cord

Affix the condensation strip under the work surface of cabinet. Please ensure

th e con dens ation strip is flu sh w ith ed ge of w or k surface.

Plac e t he di sh washe r into pos ition.

Level the dishwasher. The rear feet can be adjusted from the front of the dishwasher

by turning th e scre ws o n the left a nd r ight h and si de of the c abin et (Illustra tion 6A).

To adjust the front feet, use a wrench and turn the front feet until the dishwasher is level

(Illustration 6B).

9 The dishwasher must be secured in place. There are two ways to do this:

A. Normal work surface-secure to the work surface by using two woodscrews ensuring

the dis hwash er w eight is not being hit by the surface (I llustr ation 7).

B. Marble or granite work top-secure the bracket to the side panel of the dishwasher

an d secu re the di shwas her to the furn iture h ous ing. Pu t the rubb er c ap ove r the scre w

(Illustration 8).
