Installation of aesthetic panel
【】
Figure4a
2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the
outer door of dishwasher(see figure 4a).After positioningof the panel , fix the
panel onto the outer door by screws and bolts(See figure 4b).
Installationof aesthetic
wooden panel
【】
Figure4b
1.Takeaway the cover
2. Pin up thescrew
3. Get back the cover
19
1
1
22
Outer door
The hook is lifted from position 1 to the appropriate place,
then pushed right to the position 2 , making the
panel and t he outer door align.
4a
Outer door of
dishwasher
Aesthetic panel
Hook for aesthetic panel
ST4 screw
Spacer for aesthetic panel
ST4 screw
Hook for aesthetic panel
Cover
4b
