Bomann GSPE 773.1 [25/32] Figure 7

Bomann GSPE 773.1 [25/32] Figure 7
【】
Figure 7
21
5
4
6
2
RUBBER
SCREW
COVER
7
SCREW
CONE GEAR
5B
1
5A
1
2
.
3.
4.
5.
6
7
8
Install the fu rniture doo r to the outer door of the dishwasher using the brack e ts provided.
Refer to the template for positioning of the brackets.
Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to
tight e n the left and right door springs. Failure to do this c ould cause damage to your
dishwasher (Illustration 2)
Connect the inlet hose to the cold water supply
Connect the drain hose. Refer to diagram (Figure 6)
Connect the power cord
Affix the condensation strip under the work surface of cabinet. P lease ensure the
condensation strip is flu sh with edge of wor k surface.
Place the dishwa sher into position.
Level the dishwa sh e r. The rea r feet can be adjusted from the front of the dis hwasher by
turning the screws on the left and right hand side of the cabinet (Illustration 5A). To adjust
the front feet, use a wre nch and turn the front feet until th e dishwasher is level (Illustration 5B).
9 The dishwasher must be secured in place. Th ere are two ways to do this:
A. Normal work surface-secure t o the work surface by using two w oodscrews ensuring the
dishwasher weight is not being hit by the surface ( Illustration 6).
B. Marble or granite work top-sec ure th e bracket to t he side panel of the dishw asher and secure
the dishwasher to the furn iture housi ng. Pu t the rubber cap over the screw (Illustration 7).
