Ensu re the v oltag eand frequ enc yof thep ower be ing cor respond sto
t hose on the rating pl ate. Onl yin sert the plug into an elec trica l so cke t which i sea rthed
pr op erly. If th e el ectri cal sock et t o whi ch the a ppl ianc emu st b ec onne cte dis not
appropriate fortheplug, replacethe socket, ratherthan usingaadaptors orthelike as
they couldcause overheatingan dburns.
Plea se l ook at th era ting label to know the rat ing v olta ge a nd c on nect t he d ishwasher to t he app ropr iate power s upply.
Use the r equ ired fuse 1 0 amp ,tim ed ela yf use or c ircui tbre ak er r ecommended and provide sepa rat e circ uit servi ng
only this applianc e.
22
Di shwa she r m ust be lev el for proper dis h rack oper ati on a nd wa sh per form ance.
Place level on door and rack trackinside the tub as shown to check thatthe
dishwasheris level.
level the dishwasher by adjusting the four leveling legs individually.
When level the dishwasher, please pay attentionnot to let the dishwasher tip over.
1
2
3
Illustration of feet adjustment
【】Figure 8
Check level
side to side
Level
to Back
Front
Check
NOTE:
The maximum adjustment
height of the feet is 60 mm.
For personal safety:
Do not use an extension cor d or an adapter plug
with this appliance.
Do not, under any circumstances, cut or remove the earthing
Connection from the power cord.
