- 10 -
Round way airfl ow
4 way independent airfl ow
Moving eye panel optional
ABH071H1ERG
ABH090H1ERG
CASSETTE MODELS
YR-HBS01
180° sine wave
DC motor
Sleep mode
Evaporator
self-cleaning
DRY function
Auto mode Auto-swing
Double 8 display
Drain
water pump
4 fan settings
Auto restart
24 hours timer
Child lock
Branch outlet
Widely
electricity Hz
-20°C heating
-15°C cooling
Self-diagnosis
function
3 minutes
protection
Built-in valve
Fresh air connection
Group
control
Central
control
BMS
Model
Indoor unit ABH071H1ERG ABH090H1ERG ABH105H1ERG
Outdoor unit 1UH071N1ERG
1UH090N1ERG 1UH105N1ERG
Nominal
performance
data
Nominal capacity
Cooling
kW nom (min~max) 7.1 (2.0-8.0) 9.0 (2.5-10) 10.0 (2.5-11)
Heating
kW nom (min~max) 7.8 (2.0-9.0) 10.1 (2.5-11) 10.6 (2.5-11.3)
Rated power input
Cooling
kW nom (min~max) 1.89 (0.4-3.2) 2.56 (0.5-3.5) 2.99 (0.5-4.0)
Heating
kW nom (min~max) 2.0 (0.4-3.2) 2.69 (0.5-3.5) 2.86 (0.5-4.0)
EER
W/ W 3.75 3.52 3.34
COP W/W 3.9 3.75 3.7
Energy class (Cooling/Heating) 2.5 star / 3 star 2 star / 2.5 star 1.5 star / 2.5 star
Indoor Unit
Electrical
Power supply Ph/V/Hz
1/220-240/50/60
Performance
Air fl ow (H/M/L)
m3/h 1260/1070/820/680 1470/1260/1050/940 1680/1530/1320/1190
L/S 350/295/225/185 405/350/290/260 465/425/365/330
Sound power level (H/M/L) dB(A) 52 57 62
Sound pressure level (H/M/L) dB(A)
36/33/29/26 41/36/33/29 45/42/38/34
Installation
External dimensions (W/D/H) mm
840/840/246
Shipping dimensions (W/D/H) mm
990/990/310
Weight Net/Shipping kg
31/36
Wireless Controller optional
YR-HBS-01
Wired Controller optional
YR-E17 / YR-E16A
Panel
Panel Model
PB-950KB (standard panel)
PB-950MB (sensor panel)
External dimensions(W/D/H) mm
950*950*50
Shipping dimensions(W/D/H) mm
1000*1000*110
Weight Net/Shipping kg
6.5/9
Outdoor Unit
Electrical
Power supply Ph/V/Hz
1/220-240/50/60
Rated Current
Cooling Amps 8.7 11.6 13.6
Heating Amps 9.1 11.9 12.7
Maximum Current Amps 15.0 16.0 18.2
Performance
Air fl ow (H)
m3/h
3200 3500 4000
L/S 885 970 1110
Sound power level dB(A) 64 66 68
Sound pressure level dB(A) 47 50 52
Installation
External dimensions (H/W/D) mm
965/950/370
Shipping dimensions (H/W/D) mm
1095/1050/450
Weight Net/Shipping kg
80/92
82/94
Compressor type
Rotary
Refrigerant type
R410A
Refrigerant liquid pipe mm
9.52
Refrigerant gas pipe mm
15.88
Max pipe length m
50
Max drop between I.U.&O.U m
30
refrigerant pre- charged kg
2.5
Pre-charge line length m
20
Additional gas charge g/m
45
Working temp.
Cooling(Min-Max)
°C
-15 ~ +50
Heating(Min-Max)
°C
-20 ~ +24
DRED
WI-Fi Control
Compatible
Blue
B
u
e
ABH105H1ERG
