Haier ABH071H1ERG [11/16] Cassette models

Haier ABH071H1ERG [11/16] Cassette models
- 11 -
Round way airfl ow
4 way independent airfl ow
Moving eye panel optional
ABH125K1ERG
ABH140K1ERG
CASSETTE MODELS
YR-HBS01
Model
Indoor unit ABH125K1ERG ABH125K1ERG ABH140K1ERG
Outdoor unit 1UH125P1ERG 1UH125P1ERK 1UH140P1ERK
Nominal
performance
data
Nominal capacity
Cooling
kW nom (min~max) 12.5 (3.5~14.5) 12.5 (3.5~14.5) 13.4 (3.5~15.5)
Heating kW nom (min~max) 13.1 (4~17) 13.1 (4~17) 14.5 (4.0~18.0)
Rated power input
Cooling
kW nom (min~max) 3.67 (1.0-6.0) 3.67 (1.0-6.0) 4.05 (1.0-6.5)
Heating kW nom (min~max) 3.71 (1.0-6.0) 3.71 (1.0-6.0) 4.11 (1.2-6.8)
EER W/W 3.41 3.41 3.31
COP W/W 3.53 3.53 3.53
Energy class (Cooling/Heating) 2 star / 2 star / /
Indoor Unit
Electrical Power supply Ph/V/Hz 1/220-240/50/60
Performance
Air fl ow (H/M/L)
m3/h 1950/1600/1440/1200 1950/1600/1440/1200 1950/1600/1440/1200
L/S 540/440/400/330 540/440/400/330 540/440/400/330
Sound power level (H/M/L) dB(A) 64 64 64
Sound pressure level (H/M/L) dB(A)
47/44/38/34 47/44/38/34 47/44/38/34
Installation
External dimensions (W/D/H) mm
840*840*288
Shipping dimensions (W/D/H) mm 990*990*380
Weight Net/Shipping kg 32/38
Wireless Controller optional YR-HBS-01
Wired Controller optional YR-E17 / YR-E16A
Panel
Panel Model
PB-950KB (standard panel)
PB-950MB (sensor panel)
External dimensions(W/D/H) mm 950*950*50
Shipping dimensions(W/D/H) mm 1000*1000*110
Weight Net/Shipping kg 6.5/9
Outdoor Unit
Electrical
Power supply Ph/V/Hz 1/220-240/50/60
Rated Current
Cooling Amps 17.0 6.1 6.8
Heating Amps 17.2 6.2 7.0
Maximum Current Amps 30.0 10.8 11.0
Performance
Air fl ow (H)
m3/h
6500 7000
L/S 1805 1940
Sound power level dB(A) 69 70
Sound pressure level dB(A) 52 53
Installation
External dimensions (H/W/D) mm
1350*950*370
Shipping dimensions (H/W/D) mm 1500*480*1090
Weight Net/Shipping kg 105/118 108/121 108/121
Compressor type Rotary
Refrigerant type R410A
Refrigerant liquid pipe mm 9.52
Refrigerant gas pipe mm 15.88
Max pipe length m 75
Max drop between I.U.&O.U m 30
Refrigerant pre- charged kg 3.7
Pre-charged line length m 30
Additional gas charge g/m 45
Working temp.
Cooling (Min-Max) °C
-15 ~ +50
Heating (Min-Max) °C -20 ~ +24
180° sine wave
DC motor
Sleep mode
Evaporator
self-cleaning
DRY function
Auto mode Auto-swing
Double 8 display
Drain
water pump
4 fan settings
Auto restart
24 hours timer
Child lock
Branch outlet
Widely
electricity Hz
-20°C heating
-15°C cooling
Self-diagnosis
function
3 minutes
protection
Built-in valve
Fresh air connection
Group
control
Central
control
BMS
DRED
WI-Fi Control
Compatible
Blue
B
u
e
