Air outlet connection
Pre-set fresh air inlet
Built-in high head drain pump
Auto-swing
DRY function
Drain
water pump
4 fan settings
Auto restart
24 hours timer
Child lock
Compact design
Self-diagnosis
function
DC motor
Sleep mode
Evaporator
self-cleaning
Auto mode
Fresh Air Connection
Wi-Fi Control
Compatible
DC fan motor
700x700mm new panel design
Pre-set fresh air inlet
Built-in high head drain pump
Model/indoor unit AB09CS2ERA AB12CS2ERA(S) AB18CS2ERA(S) AB24ES1ERA(S)
Capacity
Electrical
Nominal Cooling
kW nominal
(min-max)
2.6
3.50
(0.9-4.5)
5
(1.8-5.8)
7.1
(2-7.3)
Nominal Heating
kW nominal
(min-max)
2.9
3.7
(1-4.8)
5.2
(2-6.5)
7.1
(2.5-8)
Power supply Ph/V/Hz 1/220-230/50/60 1/220-230/50/60 1/220-230/50/60 1/220-230/50/60
Performance
Air fl ow(H/M/L)
m3/h 700/620/520/450/350 700/620/520/450/350 780/700/620/500/400 1300/1100/870
l/s 194/172/144/125/97 194/172/144/125/97 216/194/172/138/111 361/305/241
Sound power level(H/M/L) dB(A) 52 52 57 59/57/52
Sound pressure level(H/M/L) dB(A) 42/40/36/32/28 42/40/36/32/28 44/42/37/35/31 46/44/39
Installation
External dimensions(W/D/H) mm 570/570/260 570/570/260 570/570/260 840/840/240
Shipping dimensions(W/D/H) mm 718/680/380 718/680/380 718/680/380 930/930/330
Net/Shipping weight kg 17/20 18.5/22 18.5/22 25.5/30.5
Refrigerant liquid pipe mm 6.35 6.35 6.35 9.52
Refrigerant gas pipe mm 9.52 9.52 12.7 15.88
Controller
Standard YR-E17 YR-E17 YR-E17 YR-E17
Optional YR-E16B / YR-HD
Wi-Fi KZW-W001 KZW-W001 & YCJ-A002
Panel
Model PB-700IB PB-950JB
External dimensions(W/D/H) mm 700/700/60 950/950/60
Shipping dimensions(W/D/H) mm 740/750/115 985/985/115
Net/Shipping weight kg 2.8/4.8 6.0/7.5
YR-E17
Controls
Standard Optional
YR-E17
YR-HD
YR-E16B
For comprehensive controls
features, see controls page
WI-Fi
Soft mode
AB24ES1ERA(S) requires YCJ-A002 for Wi-Fi connection
CASSETTE
