Haier 4U30HS2ERA [14/24] Features benefits

- 14 -

Built-in high head drain pump

Condensed water lift up to 750mm, which will allow

for a ﬂ exible installation

720mm

250mm

Medium Static Duct

The height of the medium static ducted indoor unit is

250mm only, for installation ﬂ exibility.

Return air choices

Friendly design: Rear or bottom air return is available

by removing a few screws and relocating a panel.

Rear air return

Bottom Return air

Left or Right Drain Outlet

Drain direction can be left or right according to the

layout.

DC Fan Motor

Haier adopts latest DC technology. As a

general rule a DC motor uses less energy

when compared to AC motor. An added

beneﬁ t is easy setting of the static

pressure via the remote controller.

Design Flexibility

420mm

185mm

Slim Low Static Duct

The height of the slim low static duct is 185mm only,

which is better than industry allowing for the slim-

mest ceiling cavity.

Max.

750mm

FEATURES & BENEFITS

100

40%

35%

25%

100

90%

87.5%

85%

Torque(kgfcm)

Rev(r/min) Rev(r/min)

Torque(kgfcm)

0 200 400 600 800 10000 20 400 600 800 1000
