![LG 42PC1RR [87/102] Appendix](/views2/1081322/page87/bg57.png)
APPENDIX
85
1122.. OOSSDD SSeelleecctt ((CCoommmmaanndd22::ll))
To select OSD (On Screen Display) on/off when con-
trolling remotely.
Data 0: OSD off
Data 1: OSD on
Transmission [k][l][ ][Set ID][ ][Data][Cr]
Acknowledgement [l][ ][Set ID][ ][OK][Data][x]
1133.. RReemmoottee CCoonnttrrooll LLoocckk MMooddee ((CCoommmmaanndd22::mm))
To lock the remote control and the front panel
controls on the set.
Data 0: Lock off Data 1: Lock on
If you’re not using the remote control and front panel
controls on the set, use this mode. When main power
is on/off, remote control lock is released.
Transmission [k][m][ ][Set ID][ ][Data][Cr]
Acknowledgement [m][ ][Set ID][ ][OK][Data][x]
1144.. PPIIPP // DDWW ((CCoommmmaanndd22::nn))
To control the PIP (Picture In picture)/DW.
You can also control the PIP/DW using the PIP but-
ton on the remote control or in the PIP/DW menu.
Data 0:PIP/DW off Data 1: PIP
Data2: DW1 Data3: DW2
Data5: POP
Transmission [k][n][ ][Set ID][ ][Data][Cr]
Acknowledgement [n][ ][Set ID][ ][OK][Data][x]
1155.. PPIIPP PPoossiittiioonn ((CCoommmmaanndd22::qq))
To select sub picture position for PIP.
You can also adjust the sub picture position using
POSITION button on the remote control or in the
PIP/DW menu.
Data 0: Right down on screen
Data 1: Left down on screen
Data 2: Left up on screen
Data 3: Right up on screen
Transmission [k][q][ ][Set ID][ ][Data][Cr]
Acknowledgement [q][ ][Set ID][ ][OK][Data][x]
1166.. TTrreebbllee ((CCoommmmaanndd 22 ::rr))
To adjust treble.
You can also adjust treble in the SOUND menu.
Data Min: 0 ~ Max: 64
Refer to ‘Real data mapping 1’. See page 86.
Transmission [k][r][ ][Set ID][ ][Data][Cr]
Acknowledgement [r][ ][Set ID][ ][OK][Data][x]
1177.. BBaassss ((CCoommmmaanndd 22 :: ss))
To adjust bass.
You can also adjust bass in the SOUND menu.
Data Min: 0 ~ Max: 64
Refer to ‘Real data mapping 1’. See page 86.
Transmission [k][s][ ][Set ID][ ][Data][Cr]
Acknowledgement [s][ ][Set ID][ ][OK][Data][x]
1188.. BBaallaannccee ((CCoommmmaanndd22::tt))
To adjust balance.
You can also adjust balance in the SOUND menu.
Data Min: 0 ~ Max: 64
Refer to ‘Real data mapping 1’. See page 86
Transmission [k][t][ ][Set ID][ ][Data][Cr]
Acknowledgement [t][ ][Set ID][ ][OK][Data][x]
1199.. CCoolloouurr TTeemmppeerraattuurree ((CCoommmmaanndd22::uu))
To adjust colour temperature.
You can also adjust CSM in the PICTURE menu.
Data 0: Cool 1: Normal 2: Warm 3: User
Transmission [k][u][ ][Set ID][ ][Data][Cr]
Acknowledgement [u][ ][Set ID][ ][OK][Data][x]
2200.. RReedd AAddjjuussttmmeenntt ((CCoommmmaanndd22::vv))
To adjust red in colour temperature.
Data Min: 0 ~ Max: 50
Refer to ‘Real data mapping 2’. See page 86
Transmission [k][v][ ][Set ID][ ][Data][Cr]
Acknowledgement [v][ ][Set ID][ ][OK][Data][x]
2211.. GGrreeeenn AAddjjuussttmmeenntt ((CCoommmmaanndd22::ww))
To adjust red in colour temperature.
Data Min: 0 ~ Max: 50
Refer to ‘Real data mapping 2’. See page 86
Transmission [k][w][ ][Set ID][ ][Data][Cr]
Acknowledgement [w][ ][Set ID][ ][OK][Data][x]
2222.. BBlluuee AAddjjuussttmmeenntt ((CCoommmmaanndd22::$$))
To adjust red in colour temperature.
Data Min: 0 ~ Max: 50
Refer to ‘Real data mapping 2’. See page 86
Transmission [k][$][ ][Set ID][ ][Data][Cr]
Acknowledgement [$][ ][Set ID][ ][OK][Data][x]
2233.. PPIIPP IInnppuutt SSeelleecctt ((CCoommmmaanndd 22 :: yy))
To select input source for sub picture in PIP/DW picture
mode. You can also adjust input source for sub picture
using PIP INPUT button on remote control.
Date 0: TV Date 1: AV1
Date 2: AV2 Date 3: S-Video2
Date 4: AV3 Date 5: AV4
Date 6: Component Date 7: RGB
Date 8: HDMI/DVI
Transmission [k][y][ ][Set ID][ ][Data][Cr]
Acknowledgement [y][ ][Set ID][ ][OK][Data][x]
