LG 42PC1RR [88/102] Appendix

APPENDIX

RReeaall ddaattaa mmaappppiinngg 11

0 : Step 0

A : Step 10 (Set ID 10)

F : Step 15 (Set ID 15)

10 : Step 16 (Set ID 16)

64 : Step 100

6E : Step 110

73 : Step 115

74 : Step 116

C7: Step 199

FE : Step 254

FF : Step 255

RReeaall ddaattaa mmaappppiinngg 22

0:-40

1:-39

2:-38

28 : 0

4E : +38

4F : +39

50 : +40

2244.. AAbbnnoorrmmaall SSttaattee ((CCoommmmaanndd22::zz))

To recognize an abnormal state.

This feature is not available for all models.

Data FF: Read

Data 0: Normal (Power on and signal exist)

Data 1: No signal (Power on)

Data 2: Turn the set off by remote control

Data 3: Turn the set off by sleep time function

Data 4: Turn the set off by RS-232C function

Data 5: 5V down

Data 6: AC down

Data 7: Turn the set off by Fan Alarm function (option)

Data 8: Turn the set off by Off time function

Data 9: Turn the set off by Auto sleep function

* This function is “read only”.

Transmission [k][z][ ][Set ID][ ][Data][ ][Cr]

Acknowledgement [z][ ][Set ID][ ][OK][Data][x]

2255.. IISSMM MMeetthhoodd ((CCoommmmaanndd11::jj,, CCoommmmaanndd22::pp)) ((ooppttiioonn))

To control the ISM method. You can also adjust ISM

Method in SPECIAL menu.

This feature is not available for all models.

Data 0: Normal Data 1: White Wash

Data2: Orbiter Data3: Inversion

Transmission [j][p][ ][Set ID][ ][Data][Cr]

Acknowledgement [p][ ][Set ID][ ][OK][Data][x]

2266.. LLooww ppoowweerr ((CCoommmmaanndd11::jj,, CCoommmmaanndd22::qq)) ((ooppttiioonn))

To reduce the power consumption of the monitor.

You can also adjust Low power in SPECIAL menu.

This feature is not available for all models.

Data 0: Off Data 1: On

Transmission [j][q][ ][Set ID][ ][Data][ ][Cr]

Acknowledgement [q][ ][Set ID][ ][OK][Data][x]

2277.. OOrrbbiitteerr TTiimmee SSeettttiinngg ((CCoommmmaanndd11::jj,, CCoommmmaanndd22::rr)) ((ooppttiioonn))

To adjust orbiter operation time term.

This feature is not available for all models.

Data Min: 1 ~ Max: FE

Refer to ‘Real data mapping 1’.

Transmission [j][r][ ][Set ID][ ][Data][ ][Cr]

Acknowledgement [r][ ][Set ID][ ][OK][Data][x]

3300 .. AAuuttoo CCoonnffiigguurree ((CCoommmmaanndd11::jj,, CCoommmmaanndd22::uu)) ((ooppttiioonn))

To adjust picture position and minimize image

shaking automatically. It works only in RGB (PC)

mode.

Data 1: To set

Transmission [j][u][ ][Set ID][ ][Data][Cr]

Acknowledgement [u][ ][Set ID][ ][OK][Data][x]

3311.. PPrrooggrraammmmee sseelleeccttiioonn ((CCoommmmaanndd11::mm,, CCoommmmaanndd22::aa))

To select a programme for the main picture.

Data 0: Min: 0 ~ Max: 63 (0 ~ C7, 200Pr is on)

Refer to ‘Real data mapping 1’.

Data 1: Don’t care

Data 2: 0 : Main

1 : Sub

Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1]

[ ][Data2][Cr]

Acknowledgement [a][ ][Set ID][ ][OK][Data0][x]

2288.. OOrrbbiitteerr PPiixxeell SSeettttiinngg ((CCoommmmaanndd11::jj,, CCoommmmaanndd22::ss)) ((ooppttiioonn))

To adjust pixel number in orbiter function.

This feature is not available for all models.

Data Min: 1 ~ Max: 3

Refer to ‘Real data mapping 1’.

Transmission [j][s][ ][Set ID][ ][Data][Cr]

Acknowledgement [s][ ][Set ID][ ][OK][Data][x]

2299..

PPiiccttuurree SSiizzee SSeettttiinngg ffoorr TTwwiinn PPiiccttuurree MMooddee

((CCoommmmaanndd 11 :: jj,, CCoommmmaanndd 22 :: tt)) ((ooppttiioonn))

To adjust pixel number in orbiter function.

This feature is not available for all models.

Data Min: 0 ~ Max: 20

Refer to ‘Real data mapping 1’.

Transmission [j][t][ ][Set ID][ ][Data][Cr]

Acknowledgement [t][ ][Set ID][ ][OK][Data][x]
