4
English
*Be sure to check the nameplate on product as it is subject to change by areas.
SPECIFICATIONS
Voltage (by areas)* (110V, 120V, 220V, 230V, 240V)
Power Input 200 W*
No-load speed 14000 min
–1
Sanding pad size 110 mm × 190 mm
Sanding paper size 110 mm × 100 mm (Square), 96 mm × 96 mm × 96 mm (Triangle)
Weight (without cord) 1.0 kg
STANDARD ACCESSORIES
䡬 110 × 100 mm Velcro type sanding paper
(Square).......................................................................1
䡬 96 × 96 × 96 mm Velcro type sanding paper
(Triangle) .....................................................................2
䡬 Dust bag ......................................................................1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
1. Sanding paper
䡬 110 × 100 mm Velcro type sanding paper (Square)
Grain: AA60, AA100, AA150
䡬 96 × 96 × 96 mm Velcro type sanding paper (Triangle)
Grain: AA60, AA100, AA150
2. Punch plate
Optional accessories are subject to change without notice.
APPLICATIONS
Mainly used for the following purposes at corners or
gaps.
䡬 Finish polishing of woodwork surfaces
䡬 Sanding surfaces of woodwork or sheet metal prior
to painting, etc.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If
the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Installing the sanding paper
(1) Align the sanding paper’s holes with the pad’s holes
(Fig. 1).
(2) Strongly push the sanding paper with the palm of
your hand to fasten it securely in place (Fig. 2).
5. Attaching and Removing the Dust Bag
(1) Attaching the Dust Bag
As shown in Fig. 3, hold the dust gate and push it in
the direction of Arrow A to attach it to the dust outlet.
(2) Removing the Dust Bag
As shown in Fig. 3, hold the dust gate and pull it in
the direction of Arrow B to remove it from the dust
outlet.
CAUTION
Prior to the sanding operation, make sure the material
of surface you are going to sand.
If the surface under sanding operation is expected to
generate harmful / toxic dusts such as lead painted
surface, make sure the dust bag or appropriate dust
extraction system is connected with dust outlet tightly.
Wear the dust mask additionally, if available.
Do not inhale or touch the harmful / toxic dusts
generated in sanding operation, the dust can
endanger the health of yourself and bystanders.
PRACTICAL OPERATING PROCEDURES
CAUTION
Never apply water or grinding fluid when sanding.
This could result in electrical shock.
1. Switching the sander ON and OFF
The power can be turned on by setting the lever to
ON (1) and turned off by setting the lever to OFF (0).
CAUTION
Never turn the power switch ON when the sander is
contacting the surface to be sanded. This is necessary
to preclude damage to the material. The same applies
when switching the power OFF.
2. How to hold the orbital sander
While gripping the housing, lightly press the sander
against the surface to be sanded so that the sanding
paper uniformly contacts the surface, as shown in
Fig. 4. DO NOT apply excessive pressure to the sander
while sanding. Excessive-pressure may cause
overload of the motor, reduced service life of the
sanding paper, and lowered sanding or polishing
efficiency.
CAUTION
Do not press on the corner of the pad with excessive
force. It may cause damage to the pad itself.
3. How to move the orbital sander
For optimum operating efficiency, alternately move
the sander forward and backward at a constant speed
and balance.
