LG HT353SD [14/14] Specifications
![LG HT353SD [14/14] Specifications](/views2/1081710/page14/bge.png)
14
MP3 / WMA disc compatibility with this player is limited as
follows:
• Sampling frequency: within 8 - 48 kHz (MP3),
within 22.05 - 48kHz (WMA)
• Bit rate: within 8 - 320kbps (MP3), 32 - 256kbps (WMA)
Support Ver : v2 , v7, v8, v9
• File extensions: “.mp3” / “.wma”
• CD-ROM file format: ISO9660
• We recommend that you use Easy-CD Creator, which creates
an ISO 9660 file system.
• The total number of characters for file name: maximum 8
characters (excluding file extensions like mp3/wma)
• They should not contain special letters such as / ? * : “ < > l
etc.
• The total number of files on the disc should be less than 650.
• This player can not support files with such as extention s as
bmp,zip.
• In case of spec.out file will be skip to the next file
automatically,while playing of file in order.
Customers should note that permission is required in order
to download MP3 / WMA files and music from the Internet.
Our company has no right to grant such permission.
Permission should always be sought from the copyright
owner.
JPEG disc compatibility with this player is limited as
follows:
• Normal JPEG - Max pixel in width : 8902 pixel
• Progressive JPEG - Max pixel in width : 1609 pixel
• Maximum files : Under 650.
• Some discs may not operate due to a different recording
format or the condition of disc.
• File extensions: “.jpg”
DivX disc compatibility with this player is limited as
follows:
• Available resolution: within 720x576 (W x H) pixels
• The file name of the DivX subtitle is available by 45
characters.
• If there is impossible code to express in the DivX file, it may
be displayed as " _ " mark on the display.
• Frame rate : less than 30 fps
• If the video and audio structure of recorded files is not
interleaved, either video or audio is outputted.
• Playable DivX file: ".avi ", ".mpg ", ".mpeg ", ".divx"
• Playable Subtitle format: SubRip(*.srt/*.txt), SAMI(*.smi),
SubStation Alpha(*.ssa/*.txt), MicroDVD(*.sub/*.txt),
SubViewer 2.0(*.sub/*.txt), VobSub(*.sub)
• Playable Codec format: DIVX3.xx ", "DIVX4.xx ", "DIVX5.xx
", "MP43 ", "3IVX ".
• Playable Audio format: "AC3 ", "DTS ", "PCM ", "MP3 ",
"WMA ".
• Sampling frequency: within 32 - 48 kHz (MP3),
within 24 - 48kHz (WMA)
• Bit rate: within 32 - 320kbps (MP3), 40 - 192kbps (WMA)
• Max bitrate : USB: 4Mbps , CD: 4Mbps, DVD: 7Mbps
• For Discs formatted in Live file system ,you can not it on this
player.
• If the name of movie file is different from that of the subtitle
file,during playback of a DivX file, subtitle may not be display.
• If you play a DivX file differ from DivXspec ,it may not operate
normally.
• When you play a DivX file,voice of Microphone is not
inputted.
USB Recording with this player is limited as follow notes:
Note:
- When you stop recording during playback ,the file that has
been recorded at that time will be stored.
- External HDD, Multi Card reader ,Locked device and MP3
player is not supported.
- If you record more 648 files on CD_REC folder appears
“ERROR” on the display.
- In the state SACD,CD-G ,DTS disc USB Record is not
operated.
- During USB recording, is no sound of music and some keys
except for POWER, STOP and SLEEP key not operate.
- When you extract the device or power off while recording,
stored MP3 file can not playback or not may be formed a file.
- USB recording time can be difference according to the writing
speed of device
- During the record ,can not change any function and volume.
- When you press the Rec button on the remote control in all
function appointed sound mode return to BYPASS.
- USB port of the unit can not be connected to PC. The unit can
not be used as a storage device.
- USB record is available to within 20hz~ 16khz.
Specifications
General
Power supply Refer to the back panel of the unit.
Power consumption Refer to the back panel of the unit.
Net Weight 2.5 kg
External dimensions (WxHxD) 360 x 62 x 305 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Amplifier
Output Power Front: 45 W + 45 W (Rated Output Power 30 W, THD 10 %)
Centre*: 45 W
Surround*: 45 W + 45 W (Rated Output Power 30 W, 4 Ω at 1 kHz, THD 10 %)
Subwoofer*: 75 W (Rated Output Power 60 W, 8 Ω at 30 Hz, THD 10 %)
Speakers
SH33SD-S SH33SD-W
Impedance 4 Ω 8 Ω
Net Dimensions (WxHxD) 99 x 114 x 86 mm 156 x 325 x 320 mm
Net Weight (1EA) 0.35 kg 3.5 kg
Designs and specifications are subject to change without notice.
