7
ENGLISH
7.
EQ (
EQUALIZER Effect)
8.
VSM Press VSM to set the VIRTUAL sound.
You can enjoy surround sound simply by selecting one of the
pre-programmed sound fields according to the program you want
to listen to . Press VSM button repeatedly.
9.
ECHO VOL.(V /v
)
Adjusts echo volume
10.
MIC VOL.(V /v
)
Adjusts microphone volume
- When you connect MIC the sound will be output into all channel
11. SETUP Accesses or removes setup menu
12. MENU Accesses the menu on a DVD disc.
13. DISPLAY
1. Press DISPLAY to show various information about the disc
loaded on-screen.The displayed items differ depending on
the disc type or playing status.
2. You can select an item by pressing v / V and change or
select the setting by pressing b / B.
14. TITLE If the current DVD title has a menu, the title menu
appears on the screen. Otherwise, the disc menu may
appear.
15. b/B/v/V (left/right/up/down)Selects an option in the
menu.
16. SCAN(bb/BB) During playback, press SCAN (m or
M) repeatedly to select the required scan speed.
DVD,DivX : bb, bbb, bbbb, bbbbb,
or
BB, BBB,
BBBB, BBBBB
WMA/MP3, Audio CD : m (X2, X4, X8) or M (X2, X4, X8)
SLOW(bb/BB) In the pause mode, press SLOW
(m or M) to select required speed.
DVD : t (1/2, 1/4, 1/8, 1/16) or T (1/2, 1/4, 1/8, 1/16)
DivX : T (1/2, 1/4, 1/8, 1/16)
17.
SKIP (
..
/
>>
)During playback, press SKIP (.
or >) to go to the next chapter/track or to return to the
beginning of the current chapter/track. Press SKIP .
twice briefly to step back to the previous chapter/track.
18. VOLUME (+/-) Adjusts speaker volume.
19.
• PLAY(B) - To Play disc and file
- 1.5 speed playback
You can quickly enjoy a movie and music.
The 1.5 speed allows you to watch the pictures and listen to the
sound quicker than playing at a normal speed on the disc.
1. Press the PLAY button during the normal playback. The
screen will appear at 1.5 speed with sound .
2. To return to normal PLAY, press PLAY
- If you insert MIC to unit during 1.5 speed playback,it will
be return to normal speed or when a MIC is connected into
the unit 1.5 speed playback not operate.
- FM mode state,selects MONO or STEREO by pressing
on the remote control PLAY button
• PAUSE/STEP (X) During playback, press X to pause
playback.
Press X repeatedly to play Frame-by-Frame.
• STOP (
xx
)
20. PROG./MEMO.
Accesses or removes Program menu.
Enter a radio station’s frequency into the tuner.
21. REC (z) - USB direct recording
This function enable you to record music to a connected
USB storage device from AUDIO CD .
Before USB recordings, read the notes on the page 14.
1.Insert a USB device suffiicent free space to the USB port on
the unit.
2.Select DVD/CD to record from by pressing FUNCTION button
on the remote control.
AUDIO CD - Press
v / V to select the track/file you want
3. Press REC (
z) on the remote control to start record.
“USB REC” will start flashing on the display.
- When you start the USB recording ,Recording percentage rate
will be appear on the display window during the recording .
4. File will be stored to CD_REC in a format “TRK_001.mp3”
5. To stop the recording press STOP.
DivX
DVD
ALL
ACD
WMA
MP3
DVD
11
12
13
14
15
17
18
19
20
21
25
22
23
24
16
EQ
VSM
CLEAR
CLEAR
FUNCTION
INPUT
SLEEP RETURN
S-TITLE
S-TITLE
REPEA
REPEAT
ENTER Acknowledges the menu selection.
PRESET(v/V) Press PRESET +/- repeatedly to select the
preset station you want.
Each time you press the button, the DVD/CD Receiver tunes in
one preset station at a time.
Preset radio stations in the DVD/CD Receiver’s memory first
(see “Presetting radio stations”)
TUN.(-/+) (b/B) For manual tuning, press TUN (-/+)
repeatedly.
For automatic tuning, press and hold TUN. (-/+) for about two
seconds on the front panel.
• Title (Track) –Current title (or track) number/total number of
titles (or tracks).
• Chapter –Current chapter number/ total number of chapters.
• Time – Elapsed playing time.
• Audio – Selected audio language or channel.
• Subtitle – Selected subtitle.
• Angle – Selected angle/ total number of angles.
• Sound – Selected sound mode.
Note: If a button is not pressed for a few seconds, the on-
screen display disappears.
- 2 Ch Source : BYPASS →VIRTUAL → ON STAGE →PLII
MOVIE → PLII MUSIC → PLII MTRX→ BYPASS...
- 5.1Ch Source: BYPASS →VIRTUAL → BYPASS
You can choose 7 fixed sound impressions.Each time you press the
button the setting changes in the display window as shown below.
•
AUTO EQ : AUTO EQ operates only in the MP3 files which
include the Tag information in the DVD or USB function.
( ID3 Tag is operated.ver.1 only.)
- WMA file operates to Normal EQ regardless of Tag information.
NORMAL → NATURAL → ARABIC (optional) → (AUTO EQ)→
POP → CLASSIC → ROCK → JAZZ → NORMAL..
