Component Descriptions
1. SAVE - Data Protection Button
Press SAVE button, and you can manually set the data under
recording to protection mode, so as to prevent it from being
overwritten.
2. Audio Button
Press Audio button to select whether to record the sound during
recording.
3. Laser Ray Button
Pressing and holding the button, the red dot projected is the area
which is being recorded; it is used for adjusting the installation
position of the drive recorder.
