Specifications

Thank you for choosing the products of Armytek Optoelectronics Inc., Canada.

Please read this manual carefully before using the flashlight.

USER MANUAL

THE MOST TECHNICALLY ADVANCED

Armytek Optoelectronics Inc. is a Canadian manufacturer that produces powerful and reliable flashlights designed especially for your

needs. The components made in the USA and Japan. .10 years no-hassle warranty

§ Extreme beam distance up to meters. 450

§ brightness lumens.Ultimate – 1700 LED

§ Constant brightness even in -25ºC frost and with almost discharged batteries.

§ Distinct hotspot and minimal spill guarantee directed aim illumination.

§ Standard 1" body diameter matches up with most weapon mounts.

§ Reliable body, red/green/blue filters and original remote switches for comfortable Hunting and secure Military application.

§ Guaranteed durability stands up the recoil of any gun gauge and falling from 30 meters height.–

§ The flashlight works for more than 5 hours at 50 meters depth.

Warnings

Specifications are subject to change without notice.

Armytek Optoelectronics Inc.

Web: www.armytek.com Email: service@armytek.com

Address: 13-85 West Wilmot St, Richmond Hill, Ontario, L4B 1K7, Canada

Predator

Model

Predator Pro XHP35 HI

Predator Pro XP-L HI

Predator Pro XB-H

LED

Cree XHP35 High Intensity

Cree XP-L High Intensity

Cree XB-H

Optics

Smooth Reflector

Brightness stabilization type

FULL (constant light)

Light output, LED / OTF lumens*

1700 / 1400

1200 / 1000

700 / 550

Peak beam intensity, candelas

50750

47750

36200

Hotspot / spill

5° / 4 0°

4° / 40°

Beam distance*

451 meters

437 meters

380 meters

Modes, light output

(OTF lumens*) and

runtimes (measured

with 18650 Li-Ion

3400mAh until the

light output drops to

10% of the initial

value)

Turbo2

1400 lm / 1h

1000 lm / 1.3h

550 lm / 1.7h

Turbo1

800 lm / 1.7h

670 lm / 1.8h

400 lm / 1.8h

Main3

350 lm / 4h

370 lm / 3.5h

310 lm / 3.5h

Main2

150 lm / 10.5h

170 lm / 8.5h

150 lm / 8.5h

Main1

30 lm / 50h

28 lm / 36h

30 lm / 36h

Firefly2

1.7 lm / 40d

1.7 lm / 18d

2 lm / 18d

Firefly1

0.15 lm / 200d

0.35 lm / 100d

0.2 lm / 100d

Strobe2

15 Hz / 1400 lm / 2h

15 Hz / 1000 lm / 2.7h

15 Hz / 550 lm / 3.3h

Strobe1

15 Hz / 150 lm / 22h

15 Hz / 170 lm / 17h

15 Hz / 150 lm / 17h

Power source

1x18650 Li-Ion / 2x18350 Li-Ion** / 2xRCR123 Li-Ion** / 2xCR123A

Size and weight (without batteries)

Length 154mm, body diameter 25.4mm, head diameter 41mm, weight 135g

* Light output for flashlights with Warm light are about 7% less, beam distances are about 3% less.

** It is allowed to use only protected Li-Ion batteries.

1. Always follow the instructions from this manual and recommendations on battery usage.

2. Apply only the recommended power sources.

3. Do not reverse battery polarity.

4. Do not use different power sources together, i.e. old ones with new ones, charged with

discharged. Do not use different types of batteries combined as the element with less

capacity can be damaged.

5. Do not modify or recast the flashlight and its components as it will deprive you of the

warranty.

6. Do not allow water or any other liquid to leak into the flashlight.

7. Do not aim a switched-on flashlight at people's or animals' eyes – it can cause temporary

blindness.

8. Do not allow children to use the flashlight without your assistance.

The producer will not be liable for any harm done to the user if it was caused by

improper use of the product.

Care and Storage

Service and Warranty

Do not disassemble the flashlight except for unscrewing the thread ring gage and replacing the rubber button. There are no

other parts in the flashlight that can be replaced by the user.

It is recommended to clean the threads and O-rings off dirt and old grease once or twice per year. Remember that reliable protection

from water and dust cannot be provided by worn out sealing. The fouling as well as lack of lubricant cause fast wear-out of threads and

sealing rings. To clean the threads do the following:

1. Unscrew the tailcap and remove the sealing ring carefully with a toothpick (do not use sharp metal things as they can damage the ring).

2. Wipe the sealing ring thoroughly with a soft cloth (or tissue). Do not use solvents. If the sealing ring is worn out or damaged

replace it by a new one.

3. Clean the metal threads with a brush using ethanol. Be careful not to allow the applied liquid to get inside the flashlight or tailcap as

it can cause fails in functionality of the flashlight.

After cleaning lubricate the thread and the sealing ring with polyalphaolefin-based silica grease, e.g. Nyogel 760G.The application of

automotive and other improper grease can cause swelling and damage of the sealing rings.

In case of active operation and exploitation in dusty environments, it is recommended to perform cleaning and lubricating of the parts

as often as required.

Armytek provides free warranty repair for 10 years (excluding batteries, chargers, switches and connectors which have 2 years

warranty) from the date of buy with the document confirming the purchase.

Guarantee does not extend to damage during:

1. Improper usage.

2. Attempts to modify or repair the flashlight by nonqualified specialists.

3. Longtime application in chlorinated or polluted water, or other liquids (other than water).

4. High temperatures and chemicals' exposure (including the exposure of liquid from defected batteries).

5. Usage of low-quality batteries.

In case the rubber button is damaged, it should be replaced. You can also replace the switch with

the spring in the same way. Replacement order:

1. Unscrew the tailcap.

2. Unscrew the first washer inside it to take out the switch. To do so you should use needle-

nose pliers (round-nose pliers or another tool, the most suitable will be expansion pliers).

Use the tool as it is shown at the picture. To replace the rubber button unscrew the second

washer under the switch.

3. Replace the rubber button and assemble the parts in inverse sequence.
