Operation
Heating
Manual
Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP and SWING mode)
Press MODE button. For each press,operation mode
changes as follows:
Select Heating operation " " appears and Heating
operation starts.
Press FAN button. For each press, fan speed changes as
follows:
4
1
2
3
Select temp. button
Press TEMP button
Note: For cooling only type, this function is invalid.
Every time the button is pressed, temp. setting increases 1 C
Every time the button is pressed, temp. setting decreases 1 C
If the button is kept pressed, setting will increase or
decrease quickly.
Press ON/OFF button
5
Unit stops setting when entering this mode next time.
In heat mode,warm air will blow out after a short period of
time due to cold-draft prevention function.
Remote-control unit
AUTO COOL DRY HEAT
Manual
Remote
controller
FAN
AUTO COOL DRY FAN HEAT
ON
OFF
TEMP
HEALTH
FAN
MODE
SLEEP
SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1
2
3
Remote
controller
LOW MID HIGH AUTO
Manual find it in page 20
4
5
3
10
TEMP
SWING
