Haier ESA3055 [18/24] Assemble curtains top rail
![Haier ESA3055 [18/24] Assemble curtains top rail](/views2/1824244/page18/bg12.png)
HWF06XC5, HWR06XC5, ESA3055, ESAM055
Insert the side curtains into the
top and bottom rails of the air
conditioner. Fasten the curtains
to the unit with 8 short screws
13/32".
Install top rail with 3 short
screws13/32".
ASSEMBLE
CURTAINS/TOP RAIL
12
3
5
13
2
5
33
1
5
22
1
2
12
7
16
18
9
16
13
3
8
5
3
25
16
