2. PHYSICAL AND ELECTRICAL SPECIFICATIONS
Central Air Conditioning
Model: Heat Pump, HR13-D1
HR18D1VAR HR24D1VAR HR30D1VAR HR36D1VAR HR42D1VAR HR48D1VAR HR60D1VAR
Comments 1.5-Ton Outdoor HP 2-Ton Outdoor HP 2.5-Ton Outdoor HP 3-Ton Outdoor HP 3.5-Ton Outdoor HP 4-Ton Outdoor HP 5-Ton Outdoor HP
Model Status New Model New Model New Model New Model New Model New Model New Model
HB2400VD1M20 HB2400VD1M20 HB3600VD1M22 HB3600VD1M22 HB4800VD1M22 HB4800VD1M22 HB6000VD1M22-E
HW18**VD1V22(-P) HW24**VD1V22(-P) HW30**VD1V22(-P)
17,500 24,000 28,000 35,000 42,000 46,000 55000
12600 17280 20160 25200 30240 33120 39600
Net Latent Capacity (Btu/h) 4,900 6,720 7,840 9,800 11,760 12,880 15,400
SEER 13.0 13.0 13.0 13.0 13.0 13.0 13.0
Total Input Watts ˄Cooling˅ 1,730 2,180 2,460 3,060 3800 4090 5150
16,500 22,500 25,500 32,000 41,000 44,000 55,000
3.3 3.4 3.4 3.3 3.5 3.5 3.4
Heating HSPF 7.8 7.8 7.8 7.8 7.8 7.8 7.8
Total Input Watts ˄Heating˅ 1460.0 1940.0 2200.0 2840.0 3430.0 3680.0 4740.0
Airflow Rate (CFM) 1800 1800 2700 3200 3600 4000 4300
Voltage - Phase - Frequency (Hz) 208/230 - 1 - 60 208/230 - 1 - 60 208/230 - 1 - 60 208/230 - 1 - 60 208/230 - 1 - 60 208/230 - 1 - 60 208/230 - 1 - 60
Minimum Circuit Amps 8.6 11.6 12.8 16.1 20.6 21.7 33.7
Maximum Overload Amps 15 20 20 25 35 35.0 55
Type / Maker Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating Scroll
Model Number H20J153ABCA H20J213ABCA H20J223ABCA H20J293ABCA H20J383ABCA H20J403ABCA H23R543ABCA
RLA (Rated Load Amps) 6.2 8.6 9.2 11.7 14.9 15.8 25.0
LRA (Locked Rotor Amps) 41.0 60.0 60.0 73 90.0 90.0 150.0
Internal Overload Protection Yes Yes Yes Yes Yes Yes Yes
Crankcase Heater Yes Yes Yes Yes Yes Yes N/A
RLA (Rated Load Amps) 0.86 1.1 1.3 1.43 2.0 2.0 2.5
Rated Horse Power (hp) 1/8 1/6 1/4 1/3 1/3 1/3 1/2
Nominal RPM 1000 840 850 1070 960 880 1000
Input Watts 180.0 200.0 280 310 340 390 510
Diameter (In)
18" 23" 24" 23" 24" 24" 24"
No. of Blade 3 333333
Fan Material Zinc-Coated Steel ALUMINIUM ALUMINIUM ALUMINIUM ALUMINIUM Plastic-Coated Steel Plastic-Coated Steel
Fan
Specifications Subject to Change without Prior Notice
Model Number
Cooling Capacity (Btu/h)
Net Sensible Capacity (Btu/h)
Heating Capacity (Btu/h) (8.3ć)
Heating COP (8.3ć)
Performance
Electrical
Compressor
Fan Motor
with Matching Indoor Unit (Note 3)
