![Haier HR36D1VAR [6/41] Central air conditioning](/views2/1824559/page6/bg6.png)
6
Central Air Conditioning
Model: Heat Pump, HR13-D1
Number or Rows 1 111222
Tube spacings (V x H) (In) 1 x 0.85 1 x 0.85 1 x 0.85 1 x 0.85 1 x 0.85 1 x 0.85 1 x 0.85
Fins per Inch - FPI 21 21 21 21 17 17 21
Fin Type Enhanced fins Enhanced fins Enhanced fins Enhanced fins Enhanced fins Enhanced fins Enhanced fins
Tube OD and Type 3/8" Grooved 3/8" Grooved 3/8" Grooved 3/8" Grooved 3/8" Grooved 3/8" Grooved 3/8" Grooved
Gross Finned Face Area (Sq Ft) 10.8 16.0 18.4 18.4 18.4 20.9 25.8
Number of Circuits (In/Out) 4/4 4/4 5/5 5/5 7/7 9/9 10/10
Cabinet color White White White White White White White
Top cover Stamped sheet metal Stamped sheet metal Stamped sheet metal Stamped sheet metal Stamped sheet metal Stamped sheet metal Stamped sheet metal
Basepan Deep Drawn, Elevated Deep Drawn, Elevated Deep Drawn, Elevated Deep Drawn, Elevated Deep Drawn, Elevated Deep Drawn, Elevated Deep Drawn, Elevated
Service panel Easy Access Easy Access Easy Access Easy Access Easy Access Easy Access Easy Access
Full metal jacket Yes Yes Yes Yes Yes Yes Yes
Wire grill Optional Optional Optional Optional Optional Optional Optional
Plastic mesh Optional Optional Optional Optional Optional Optional Optional
Galvanized Steel Cabinet Yes Yes Yes Yes Yes Yes Yes
Coil Design Haier Enhanced Coil Haier Enhanced Coil Haier Enhanced Coil Haier Enhanced Coil Haier Enhanced Coil Haier Enhanced Coil Haier Enhanced Coil
Fully Enclosed Motor Yes Yes Yes Yes Yes Yes Yes
Removable Top Grill Assembly Yes Yes Yes Yes Yes Yes Yes
Elevated Base Pan Yes Yes Yes Yes Yes Yes Yes
High and Low Pressure Switches Yes Yes Yes Yes Yes Yes Yes
Filter Dryer Yes Yes Yes Yes Yes Yes Yes
Full, Reusable Service Valves Yes Yes Yes Yes Yes Yes Yes
Easy Service Access Yes Yes Yes Yes Yes Yes Yes
Corrosion Resistant Outside Screws Yes Yes Yes Yes Yes Yes Yes
Room Thermostat Optional Optional Optional Optional Optional Optional Optional
Start Assist Kit No No No No No No No
Low Ambient Kit Optional Optional Optional Optional Optional Optional Optional
Compressor Time Delay No No No No No No No
Compressor Blanket Kit No No No No No No No
Fan Delay Kit (
Note 1 ) NoNoNoNoNoNoNo
Piston Yes Yes Yes Yes Yes Yes Yes
Height 32 1/5 28 1/4 32 3/16 32 3/16 32 3/16 36 1/8 44
Width 23 3/8 30 5/8 30 5/8 30 5/8 30 5/8 30 5/8 30 5/8
Depth 23 3/8 30 5/8 30 5/8 30 5/8 30 5/8 30 5/8 30 5/8
Cubic Volume (Cu. Ft) 10.18 15.33 17.46 17.46 17.46 19.60 23.87
3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
3/4" 3/4" 3/4" 7/8" 7/8" 7/8" 7/8"
115 115 115 115 115 115 115
Outdoor above Indoor
Unit 70 70 70 70 70 70 70
Indoor above Outdoor
Unit 50 50 50 50 50 50 50
Unit
Dimensions
(inches)
Max
Vertical
Distance
(Ft)
Refrigerant
Line
Liquid Line Dimension (In)
Vapor Line Dimension (In)
Max Refrigerant Line Length (Ft)
Exterior Appearance
Features Lug.
Accessories
Condenser coil
Body style /
Coil guard
Dimensions and Installation
