9
Operation
Hints
Remote controller can memorize settings in each operation mode. To run it next time just
select the operation mode and it will start with the previous setting.
No reelecting is needed.(TIMER ON/OFF、SLEEP、SWING needs reelecting)
Cautions: Note:
On cooling only unit, heating mode is not available, The above information is the
After replacing batteries, press ON/OFF, and display explanation of the displayed
becomes as follows: information therefore varies
Operation mode: AUTO, Temp. :No with those displayed in actual
operation.
Auto Operation
ON/OFF TEMP
SET
TIMER
CLOCKSWING
SLEEP
LOCK
RESET
FAN
MODE
HEALTH
(1) Unit start
Press ON/OFF on the remote controller, unit starts .
(2) Select operation mode
Press MODE button. For each press, operation mode
changes as follows:
Remote controller:
Then
Select Auto operation
AUTO COOL DRY FAN
Press FAN button. For each press, fan speed changes
as follows:
Remote controller:
(3) Fan speed selection
Air conditioner is running under displayed fan speed.
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
(4)Unit stop
Press ON/OFF button, the unit stops.
3
4
1
2
LO MED HIAUTO
