4
Names of the parts
Packing list
Fully automatic
washing machine
Water inlet hose Bottom plate Tapping screws
(One Package)
User’s manual
Warranty card
Control panel seat
Top lid component
Back cover
Power line
Drain hose
Cabinet handle
Water inlet valve
Water absorption cushion
Hanging hole
Filter cover
Control panel film
Upper cabinet
Lower cabinet
Adjustable foot
Trundle control handle
Adjustable foot film
Screw cover(right)
Screw cover(left)
Outer tub cover
Lint filter A
Balance ring
Inner tub
Liquid whitener inlet
Detergent inlet
Fixed foot(3 pieces)
Lint filter B
Pulsator
All illustrations in this Manual are
given for reference only. Your
products and accessories may
show differences from these
illustrations due to our continuous
improvement.
The lint filter B which is opposite to
the lint filter A can be used as
detergent box.
