Haier HWM90-1678T [3/20] Product overview
![Haier HWM90-1678T [3/20] Product overview](/views2/1827883/page3/bg3.png)
Please understand that the shapes of the washing machine and accessories may
●
be different from the sketch figures in this manual due to product improvement.
Handle
Back cover
Power cord
Water inlet valve
Fixed foot
(2 pieces)
Hook
Drain hose
Product overview
Detergent box
Top lid component
Pulsator
Cabinet
Base frame
Control panel
Control panel seat
Inner tub
Adjustable foot
(2 pieces)
Lint filter
