Specifications
General Specifications
TX6n TX5n TX4n
120V 230V (*1) 120V 230V (*1) 120V 230V (*1)
Output
Power
1kHz,
THD + N = 1%
8Ω per channel 1800W 1800W 1300W 1300W 1100W 1100W
4Ω per channel 3000W 3000W 2200W 2300W 1900W 2000W
2Ω per channel 2750W 2750W 2500W 2500W 2200W 2200W
8Ω bridge 6000W 6000W 4400W 4600W 3800W 4000W
4Ω bridge 5500W 5500W 5000W 5000W 4400W 4400W
20ms burst 2Ω per channel 4100W 4120W 3480W 3600W 2990W 3050W
4Ω bridge 8200W 8240W 6960W 7200W 5980W 6100W
Constant voltage line
—
STEREO mode :
100V line, 1250W / 8Ω
BRIDGE mode :
200V line, 2500W / 16Ω
—
Voltage
Gain
RL = 8Ω
Analog input to speaker output
43.8dB – 19.8dB,
0.1dB step
43.8dB – 19.8dB,
0.1dB step
43.8dB – 19.8dB,
0.1dB step
Input
Sensitivity
RL = 8Ω
Analog input to speaker output
0.0dBu – 24.0dBu,
0.1dB step
-1.4dBu – 22.6dBu,
0.1dB step
-2.6dBu – 21.4dBu,
0.1dB step
SN Ratio 20Hz – 20kHz,
DIN AUDIO
Analog input to
speaker output (Input
sensitivity = +24dBu)
103dB 102dB 101dB
AES/EBU input to
speaker output
108dB 107dB 106dB
All Models
THD + N 1kHz, half power RL = 4Ω, 8Ω≤0.2%
RL = 2Ω≤0.4%
Intermodulation Distor-
tion
60Hz : 7kHz, 4 : 1, Half power (*2), RL = 4Ω, 8Ω≤0.25%
Frequency Response RL = 8Ω, Po = 1W, 20Hz – 20kHz +0dB, -1.0dB
Channel Separation Att. max, half power (*3), RL = 8Ω, 1kHz, input 600Ω shunt 65dB
Damping Factor RL = 8Ω, ≤100Hz >300
Maximum Input Level +24dBu (*4)
Attenuation 0dB – -80dB, -∞dB (0.5dB step)
Input Impedance 20kΩ (balanced), 10kΩ (unbalanced)
A/D, D/A Converter 24-bit
Sampling Frequency 96k, 88.2k, 48k, 44.1kHz
Signal Processing 32bit DSP
Signal Delay Analog input to speaker output fs = 96kHz 729us
fs = 48kHz 1.13ms
AES/EBU input to speaker output fs = 96kHz 708us
fs = 48kHz 1.02ms
Analog input to AES/EBU output fs = 96kHz 396us
fs = 48kHz 583us
AES/EBU input to AES/EBU output fs = 96kHz 365us
fs = 48kHz 479us
AES/EBU input to AES/EBU though output 0.04us
Controls Front panel POWER switch (rocker),
Rotary encoder x 2,
Function button x 4, HOME button x 1,
EXIT button x 1, ENTER button x 1,
Mute button x 2
