8
ENGLISH
(Original instructions)
u Run the battery down completely, then remove it from the
tool.
u NiCd, NiMH and Li-Ion batteries are recyclable. Take them
to any authorised repair agent or a local recycling station.
Technical data
EGBHP146
(H1)
Voltage V
DC
14.4
No-load speed Min
-1
0-350/
0-1500
Max. torque Nm 36
Chuck capacity mm 13
Max Drilling capacity
Steel/wood mm 13/38
EGBHP148
(H1)
EGBHP188 /
EGBHP1881
(H1)
Voltage V
DC
14.4
18
No-load speed Min
-1
0-350/
0-1500
0-350/
0-1500
Max. torque Nm 36 43.7
Chuck capacity mm 13 13
Max Drilling capacity
Steel/wood/
masonry
mm 13/38/13 13/38/13
Charger
905713**
(typ. 1)
905998**
(typ. 1)
Input Voltage V
AC
230 230
Output Voltage
V
DC
20 (Max) 18
Current A 2 1
Approx. charge time min
40 90
Charger
905902**
(typ. 1)
Input Voltage V
AC
100 - 240
Output Voltage
V
DC
8 - 20
Current mA
400
Approx. charge time h
3 - 5
Battery BL1514
BL1518 BL2018
Voltage V
DC
14.4 18 18
Capacity Ah 1.5 1.5 2.0
Type Li-Ion Li-Ion Li-Ion
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 91.5 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 102.5 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 60745:
Impact drilling into concrete (a
h, ID
) 12.8 m/s
2
, uncertainty (K) 1.5 m/s
2
Drilling into metal (a
h, D
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
Screwdriving without impact (a
h, s
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
EC declaration of conformity
MACHINERY DIRECTIVE
%
EGBHP146 / EGBHP148 / EGBHP188 / EGBHP1881
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN 60745-1, EN 60745-2-1
These products also comply with Directive 2004/108/EC and
2011/65/EU. For more information, please contact Black &
Decker at the following address or refer to the back of the
manual.
The undersigned is responsible for compilation of the technical
le and makes this declaration on behalf of Black & Decker.
_
Kevin Hewitt
Vice-President Global Engineering
Black & Decker Europe, 210 Bath Road, Slough,
Berkshire, SL1 3YD
United Kingdom
25/04/2014
