Kentatsu KFKD38H0EN1 [14/32] Cooling capacities with fan at high speed kfkd48h0en1
![Kentatsu KFKD20H0EN1 [14/32] Cooling capacities with fan at high speed kfkd48h0en1](/views2/1830134/page14/bge.png)
14
KFKD middle static pressure duct
Cooling Capacities (with fan at high speed)
KFKD48H0EN1
KFKD48H0EN1
Air inlet condition
EWT ∆t
DB:21 WB:15 DB:26.7 WB:19.4 DB:27 WB:19 DB:29 WB:21 DB:33 WB:25
TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD
3
3.64 2.64 1.04 41.8 5.61 3.38 1.61 99.2 5.49 3.52 1.57 95.2 6.13 3.22 1.76 118.7 8.25 4.00 2.37 215.1
4
3.42 2.50 0.74 20.8 5.39 3.28 1.16 51.6 5.30 3.42 1.14 49.9 5.89 3.11 1.27 61.6 8.00 3.87 1.72 113.6
5 5
3.16 2.39 0.54 11.4 5.16 3.16 0.89 30.2 5.05 3.31 0.87 29.0 5.66 4.90 0.97 36.4 7.75 3.81 1.33 68.2
6
2.89 2.29 0.41 6.6 4.93 3.07 0.71 19.2 4.83 3.20 0.69 18.4 5.42 2.88 0.78 23.1 7.56 3.68 1.08 45.0
7
2.59 2.14 0.32 3.9 4.69 2.93 0.58 12.7 4.58 3.09 0.56 12.1 5.19 2.77 0.64 15.6 7.30 3.56 0.90 30.9
3
3.29 2.49 0.94 34.1 5.29 3.24 1.52 88.3 5.17 3.38 1.48 84.3 5.82 3.07 1.67 107.0 7.94 3.87 2.28 198.8
4
3.05 2.37 0.66 16.6 5.08 3.13 1.09 45.8 4.96 3.27 1.07 43.7 5.59 2.97 1.20 55.4 7.68 3.75 1.65 104.8
6 5
2.82 2.26 0.48 9.0 4.83 3.02 0.83 26.5 4.74 3.17 0.81 25.5 5.37 2.86 0.92 32.7 7.43 3.62 1.28 62.7
6
2.53 2.16 0.36 5.1 4.60 2.93 0.66 16.7 4.50 3.05 0.64 15.9 5.10 2.73 0.73 20.5 7.24 3.49 1.04 41.3
7
2.23 2.01 0.27 2.9 4.36 2.79 0.54 11.0 4.25 2.97 0.52 10.5 4.87 2.62 0.60 13.7 6.98 3.43 0.86 28.3
3
2.94 2.34 0.84 27.3 4.94 3.09 1.42 77.0 4.83 3.24 1.39 73.7 5.48 2.92 1.57 94.8 7.56 3.68 2.17 180.2
4
2.70 2.25 0.58 12.9 4.74 2.98 1.02 39.8 4.61 3.14 0.99 37.7 5.26 2.83 1.13 49.2 7.37 3.62 1.58 96.3
7 5
2.44 2.14 0.42 6.8 4.50 2.87 0.77 23.0 4.4 3.03 0.76 22 5.01 2.71 0.86 28.5 7.11 3.49 1.22 57.5
6
2.15 2.03 0.31 3.6 4.26 2.79 0.61 14.3 4.18 2.92 0.60 13.8 4.78 2.59 0.69 18.0 6.92 3.37 0.99 37.8
7
1.86 1.86 0.23 2.0 4.03 2.66 0.50 9.4 3.90 2.83 0.48 8.8 4.53 2.48 0.56 11.9 6.67 3.24 0.82 25.8
3
2.58 2.22 0.74 21.0 4.60 2.95 1.32 66.9 4.50 3.09 1.29 63.8 5.15 2.76 1.48 83.7 7.24 3.56 2.07 165.4
4
2.32 2.15 0.50 9.6 4.40 2.85 0.95 34.4 4.27 3.02 0.92 32.3 4.90 2.68 1.05 42.7 6.98 3.43 1.50 86.6
8 5
2.06 2.01 0.35 4.8 4.18 2.73 0.72 19.8 4.05 2.90 0.70 18.6 4.69 2.57 0.81 25.0 6.79 3.30 1.17 52.4
6
1.85 1.85 0.26 2.7 3.90 2.65 0.56 12.0 3.83 2.79 0.55 11.6 4.46 2.45 0.64 15.7 6.54 3.24 0.94 33.7
7
1.61 1.61 0.20 1.5 3.68 2.53 0.45 7.8 3.56 2.70 0.44 7.4 4.17 2.35 0.51 10.1 6.31 3.12 0.78 23.1
3
2.20 2.09 0.63 15.3 4.28 2.82 1.23 57.8 4.16 2.96 1.19 54.6 4.81 2.63 1.38 72.9 6.92 3.43 1.98 151.2
4
2.00 2.00 0.43 7.1 4.04 2.72 0.87 29.0 3.92 2.87 0.84 27.2 4.56 2.53 0.98 36.9 6.67 3.30 1.43 78.9
9 5
1.85 1.79 0.32 3.9 3.82 2.60 0.66 16.6 3.70 2.77 0.64 15.6 4.34 2.42 0.75 21.4 6.48 3.17 1.11 47.7
6
1.62 1.62 0.23 2.1 3.57 2.51 0.51 10.0 3.44 2.69 0.49 9.3 4.11 2.30 0.59 13.3 6.20 3.10 0.89 30.4
7
1.32 1.32 0.16 1.0 3.30 2.39 0.41 6.3 3.19 2.57 0.39 5.9 3.82 2.20 0.47 8.5 5.99 2.99 0.74 20.8
3
1.94 1.94 0.56 11.9 3.92 2.67 1.12 48.6 3.77 2.85 1.08 44.7 4.47 2.49 1.28 63.1 6.60 3.24 1.89 137.6
4
1.78 1.78 0.38 5.7 3.68 2.57 0.79 24.1 3.56 2.76 0.76 22.4 4.21 2.39 0.91 31.5 6.33 3.17 1.36 71.1
10 5
1.59 1.59 0.27 2.9 3.44 2.49 0.59 13.5 3.30 2.67 0.57 12.3 3.99 2.29 0.69 18.1 6.13 3.06 1.05 42.7
6
1.37 1.37 0.20 1.5 3.21 2.38 0.46 8.1 3.06 2.57 0.44 7.4 3.73 2.17 0.53 11.0 5.87 2.98 0.84 27.2
7
0.87 0.87 0.11 0.4 2.93 2.28 0.36 5.0 2.79 2.47 0.34 4.5 3.49 2.06 0.43 7.0 5.61 2.86 0.69 18.2
3
1.71 1.71 0.49 9.3 3.54 2.55 1.02 39.6 3.42 2.72 0.98 36.8 4.11 2.36 1.18 53.3 6.23 3.12 1.79 122.5
4
1.57 1.57 0.34 4.4 3.32 2.46 0.71 19.6 3.19 2.62 0.69 18.0 3.88 2.26 0.83 26.7 5.97 3.03 1.28 63.4
11 5
1.36 1.36 0.23 2.1 3.07 2.37 0.53 10.7 2.93 2.55 0.50 9.7 3.63 2.15 0.62 14.9 5.78 2.93 0.99 38.0
6
1.08 1.08 0.15 0.9 2.79 2.27 0.40 6.2 2.69 2.44 0.38 5.7 3.37 2.04 0.48 8.9 5.52 2.85 0.79 24.
0
7
0.
73
0.73 0.09 0.3 2.49 2.19 0.31 3.6 2.40 2.40 0.29 3.3 3.10 1.92 0.38 5.6 5.26 2.73 0.65 16.1
3
1.51 1.51 0.43 7.2 3.17 2.43 0.91 31.7 3.02 2.62 0.86 28.7 3.73 2.23 1.07 44.0 5.88 3.00 1.69 109.1
4
1.33 1.33 0.29 3.2 2.93 2.35 0.63 15.3 2.79 2.53 0.60 13.8 3.51 2.13 0.75 21.9 5.63 2.90 1.21 56.3
12 5
1.15 1.15 0.20 1.5 2.68 2.27 0.46 8.2 2.54 2.45 0.44 7.3 3.26 2.03 0.56 12.1 5.42 2.79 0.93 33.3
6
0.69 0.69 0.10 0.4 2.38 2.19 0.34 4.5 2.36 2.31 0.34 4.4 2.98 1.92 0.43 7.0 5.16 2.72 0.74 21.0
7
0.57 0.57 0.07 0.2 2.11 2.11 0.26 2.6 2.17 2.17 0.27 2.7 2.71 1.80 0.33 4.3 4.90 2.61 0.60 13.9
3
1.30 1.30 0.37 5.3 2.77 2.32 0.79 24.2 2.61 2.52 0.75 21.5 3.37 2.10 0.96 35.7 5.50 2.88 1.58 95.7
4
1.11 1.11 0.24 2.2 2.53 2.23 0.54 11.4 2.44 2.40 0.53 10.6 3.12 2.00 0.67 17.3 5.27 2.77 1.13 49.3
13 5
0.80 0.80 0.14 0.7 2.26 2.21 0.39 5.8 2.29 2.29 0.39 5.9 2.88 1.90 0.49 9.4 5.03 2.66 0.87 28.8
6
0.53 0.53 0.08 0.2 2.06 2.06 0.29 3.3 2.13 2.13 0.30 3.6 2.60 1.80 0.37 5.3 4.77 2.59 0.68 18.0
7
0.39 0.39 0.05 0.1 1.88 1.88 0.23 2.0 1.96 1.96 0.24 2.2 2.27 1.70 0.28 3.0 4.53 2.48 0.56 11.9
