KFKD middle static pressure duct
6
Specifications
Model KFKD_H0EN1 48 57 70
Air flow
H/M/L
m
3
/h
850/640/425 1020/765/510 1360/1020/680
H/M/L CFM 500/375/250 600/450/300 800/600/400
External Static pressure
Pa
50
Cooling
Capacity
H/M/L kW 4.4/3.74/3.25 5.5/4.58/4.09 7.5/6.33/5.68
Water flow rate
H l/h 757 946 1290
Water pressure
drop
H kPa 22 14 14
Heating
Capacity
H/M/L kW 6.8/5.78/5.07 8.1/6.77/5.92 11/9.48/8.25
Water pressure
drop
H kPa
18.3 11.8 12.5
Power supply
V/ph/Hz
220-240/1/50
Power
input
50Pa H W 89 110 130
Sound
pressure
level
12Pa
H/M/L dB(A) 39/36/32 40/36/33 42/37/33
50Pa
H/M/L dB(A) 45/41/34 46/41/35 46/41/36
Fan motor
Type
Low noise 4-speed fan motor
Quantity
1 1
2
Fan
Type
Centrifugal, forward-curved Blades
Quantity
2 2
4
Coil
Row
2
Max. working pressure
MPa
1.6
Diameter
mm Φ9.52
Body
Dimensions W
×
H
×
D
mm 912
×
241
×
506 1135
×
241
×
506 1435
×
241
×
506
Packing W
×
H
×
D
mm 971
×
265
×
558 1185
×
265
×
558 1485
×
265
×
558
Net weight
kg 20 24 33
Gross weight
kg 22.5 27 36.5
Pipe
connection
Water inlet/outlet pipe
Inch
RC3/4
Drain pipe
mm ODΦ24
Note:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling conditions: entering water 7
°
C, temperature rise 5
°
C, entering air temperature 27
°
C DB,19
°
CWB.
Heating conditions: entering water 50
°
C, enter air temperature 20
°
C, the same water flow as the cooling conditions.
3. Noise is tested in semi-anechoic test room.
