DM13-01.01.12en Neola Inverter
Service manual 13
Indoor MS11D-18HRDN1 MS11D-24HRDN1
Outdoor MO11D-18HDN1 MO11D-24HRDN1
Power supply Ph-V-Hz 220-240V~ 50Hz, 1Ph 220-240V~ 50Hz, 1Ph
Cooling
Capacity
Btu/h 18000(5100~23000) 24000(12000~25000)
kW 5,28 (1,49~6,74) 7,03 (3,52~7,33)
Input W 1640(380~2000) 2190(820~2500)
Rated current A 7.3(1.8~10.2) 9.8(3.6~11.2)
EER W/W 3.21 3.21
Heating
Capacity
Btu/h 18000(5300~24000) 25000(11000~27000)
kW 5,28 (1,55~7,04) 7,33 (3,22~7,91)
Input W 1460(350~2000) 2030(800~2700)
Rated current A 6.6(1.6~9.0) 8.9(3.5~12.0)
COP W/W 3.61 3.61
Moisture Removal L/h 1.8 2.5
Max. input consumption W 2640 3040
Max. current A 11.9 13.9
Starting current A ---- ----
Compressor
Model DA130S1C-20FZ DA150S1C-20FZ
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity Btu/h 13170 15286
Input W 990 1150
Rated current(RLA) A 4.97 9.7
Locked rotor Amp(LRA) A ---- ----
Thermal protector 1NT01L-4639 or KSD301 KSD301
Thermal protector
position
---- EXTERNAL
Capacitor uF 45 50
Refrigerant oil/oil
charge
ml ESTER OIL VG74/500 ESTER OIL VG74/500
Indoor fan
motor
Model RPG25 RPG45C
Brand Welling Broad Ocean
Input W 55 72
Capacitor uF 1.5 3.0
Speed(Hi/Mi/Lo) r/min 1250/1100/800 1200/1100/900
Indoor coil
a.Number of rows 1/2 2
b.Tube pitch(a)x row
pitch(b)
mm 21x13.37 21x13.37
c.Fin spacing mm 1.2/1.3 1.3
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and
type
mm Φ7,innergroove tube Φ7,innergroove tube
