Midea MS11D-18HRDN1 [21/56] Refrigerant cycle diagram
![Midea MS11D-18HRDN1 [21/56] Refrigerant cycle diagram](/views2/1831740/page21/bg15.png)
DM13-01.01.12en Neola Inverter
Service manual 21
6. Refrigerant Cycle Diagram
INDOO
R
OUTDOO
R
LIQUID SIDE
GAS SIDE
HEAT
EXCHANGE
(EVAPORATOR)
HEAT
EXCHANGE
(CONDENSER)
COMPRESSOR
2-WAY VALVE
3-WAY VALVE
CHECK VALVE
(Heating Model only)
CAPILIARY TUBE
REVERSING VALVE
(Heating Model only)
COOLING
HEATING
ACCUMULATOR
