3 Product Specification
3.1. CS-F24DTE5 CU-B24DBE5
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F24DTE5 CU-B24DBE5
Remote
Control
CZ-RD513C (Wired)
CZ-RL013T (Wireless)
Cooling Capacity kW 6.6
BTU/h 22,500
Heating Capacity kW 7.1
BTU/h 24,200
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min 17 60
cfm 600 2120
Outside Dimension (H x W x D) mm 210 x 1245 x 700 795 x 900 x 320
inch 8-9/32 x 49-1/64 x 27-9/16 31-5/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 33 (73) 69 (152)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set - Hermatic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 1.8
Fan Type, Number of Set Sirocco fan-4 Mix flow fan-1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.04 0.07
Air-heat Exchanger (Row x Stage x FPI) Slit-fin type (2 x 12 x 18) Corrugate-fin type (2 x 36 x 19)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged) cm
3
- FV50S (1130)
Refrigerant (Charged) R410a kg (oz) - 1.70 (60)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 43/39 50/-
Heating: 43/39 51/-
Power Level
dB
Cooling: 60/56 66/-
Heating: 60/56 67/-
Moisture Removal L/h (Pt/h) 3.8 (8.0)
EER W/W 2.63/2.57/2.51
COP W/W 2.91/2.85/2.71
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cooling 2.51 2.57 2.63
Heating 2.44 2.49 2.62
Running Current A Cooling 12.4 12.6 12.8
Heating 12.4 12.6 12.8
Starting Current A 59 62 65
Power Factor % Cooling 92 89 86
Heating 89 86 85
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
9
