Panasonic CU-A12ATP5 [6/56] Specifications are subject to change without notice for further improvement
![Panasonic CS-A24ATP5 / CU-A24ATPT5 [6/56] Specifications are subject to change without notice for further improvement](/views2/1832684/page6/bg6.png)
Unit CS-A12ATP5 CU-A12ATP5
Power Cord Length
Number of core-wire
m 2.3
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 6 - 1/2 (165) 19 - 29/32 (505)
Width inch (mm) 43 - 5/16 (1,100) 30 - 23/32 (780)
Depth inch (mm) 25 - 19/32 (650) 9 - 21/32 (245)
Net Weight lb (kg) 62 (28) 88 (40)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 1,100
Air Circulation Type SIROCCO Propeller Fan
Material STYLAC 181 AES + Glass Fiber 12%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 45.6 58.6
Rated Output W 20 20
Fan Speed Low rpm 980 —
Medium rpm 1,055 —
High rpm 1,100 730
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Louver Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
1×10 2×19
FPI 21 16
Size (W × H × L) mm 900 × 254 × 22 706 × 482 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(410)
Refrigerant (R-22) g (oz.) — 1,090 (38.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Length mm — Cooling; 625, Heating; 720
Capillary Tube Flow Rate l/min — Cooling; 13.5, Heating; 11.0
Inner Diameter mm — Cooling; 1.6, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.2 µF, 450VAC 1.2 µF, 400VAC
•
Specifications are subject to change without notice for further improvement.
6
CS-A12ATP5 CU-A12ATP5 / CS-A18ATP5 CU-A18ATPT5 / CS-A24ATP5 CU-A24ATPT5
