Unit CS-E9EKEB CU-E9EKEB
Power Cord Length
Number of core-wire
m 1.8
(1.5mm
2
)
—
—
Dimensions Height inch (mm) 11 - 1/32 (280) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 7 - 7/32 (183) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 77 (35)
Compressor Type — Hermetic Motor
Motor Type — Brushless (4-pole)
Rated Output W — 750
Fan Motor Type Cross-flow Fan Propeller Fan
Material ASG20k1 P.P
Motor Type Transistor (8-poles) Induction (8-poles)
Input W 44.3 61.3
Rate Output W 30 40
Fan Speed Lo (Cool/Heat) rpm 820/880 —
Me (Cool/Heat) rpm 1,050/1,140 —
Hi (Cool/Heat) rpm 1,280/1,400 800/790
SHi (Cool/Heat) rpm 1,320/1,440 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2/15 2/24
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 718.4
689.8
× 504 × 36.4
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — RB68A (400)
Refrigerant (R410A) g (oz) — 930 (32.8)
Thermostat Electronic Control —
Protection Device — Electronic Control
Air Filter Material
Style
P.P.
Honeycomb
—
• Specifications are subjected to change without prior notice for further improvement.
6
CS-E9EKEB CU-E9EKEB / CS-E12EKEB CU-E12EKEB
