Panasonic CS-A28BKP5 / CU-A28BKP5 [31/77] Setting the timer
![Panasonic CS-A28BKP5 / CU-A28BKP5 [31/77] Setting the timer](/views2/1833685/page31/bg1f.png)
<Note>
Regarding remote control.
■ If the current time is not set correctly, correct
Timer setting will not be possible.
■ When the Timer is set, the current time display
will vanish.
■ [RESET] points will clear the memory once
they are shorted.
■ [B ↔ A] switch is used when two air
conditioners units have been installed in one
room. Please consult your dealer.
[RESET] points
Setting the Timer
[B
↔
A] switch
If there is a power failure.
OFF-TIMER
SET
➡
To reset the Timer.
(Example) If the OFF Timer has been set.
■ Even if there is a power failure, the setting time
is still stored in the memory because the re-
mote control is a battery operated type.
q
OFF/ON
SLEEP
PM
OFF-TIMER TIME
ON-TIMER
SET
CANCEL
11:30
OPEN
31
CS-A28BKP5/CU-A28BKP5
