109
REF.
NO.
PART NAME & DESCRIPTION QTY CU-HE9NKE CU-AE9NKE CU-HE12NKE REMARK
1 CHASSIS ASSY 1 CWD52K1310 ← ←
2 SOUND PROOF MATERIAL 1 CWG302742 ← ←
3 FAN MOTOR BRACKET 1 CWD541167 ← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ←
5 FAN MOTOR 1 ARS6411AC ← ← O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
7 PROPELLER FAN ASSY 1 CWH03K1066 ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ←
9 COMPRESSOR 1 5RD132XBE21 ← ← O
10 ANTI - VIBRATION BUSHING 3 CWH50077 ← ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ← ←
12 CONDENSER 1 CWB32C3547 ← ←
14 DISCHARGE MUFFLER 1 CWB121010 ← ←
15 HOLDER COUPLING 1 CWH351233 ← ←
16 2-WAYS VALVE (LIQUID) 1 CWB021589 ← ← O
17 3-WAY VALVE (GAS) 1 CWB011374 ← ← O
19 REACTOR 1 G0C193J00004 ← ←
20 TERMINAL COVER 1 CWH171039A ← ←
21 NUT - TERMINAL COVER 1 CWH7080300J ← ←
22 SOUND PROOF BOARD 1 CWH151273 ← ←
23A SOUND PROOF MATERIAL 1 CWG302741 ← ←
23B SOUND PROOF MATERIAL 1 CWG302745 ← ←
23C SOUND PROOF MATERIAL 1 CWG302740 ← ←
24 SENSOR CO. - COMP TEMP 1 CWA50C2894 ← ← O
25 SENSOR CO. - DISCHARGE 1 CWA50C2656 ← ← O
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6851R CWA73C6859R CWA73C6852R O
27 TERMINAL BOARD ASSY 1 CWA28K1036J ← ← O
28 CABINET SIDE PLATE CO. 1 CWE04C1411 ← ←
29 SENSOR CO.- AIR AND PIPE TEMP 1 CWA50C2893 ← ← O
30 CABINET SIDE PLATE (L) 1 CWE041579A ← ←
31 CABINET FRONT PLATE CO. 1 CWE06C1441 ← ←
32 CABINET TOP PLATE 1 CWE031148A ← ←
33 PLATE - C.B.COVER 1 CWH131470A ← ←
34 CONTROL BOARD COVER CO. 1 CWH13C1253 ← ←
35 CONTROL BOARD COVER 1 CWH131473 ← ←
36 CRANKCASE HEATER (BASE PAN) 1 CWA341072 ← ←
38 4-WAYS VALVE 1 CWB001037J ← ←
39 V-COIL COMPLETE 1 CWA43C2431 ← ←
40 WIRE NET 1 CWD041166A ← ←
41 HOLDER SENSOR 1 CWH32075 ← ←
42 HOLDER SENSOR 2 CWH32143 ← ←
43 CRANKCASE HEATER 1 CWA341044 ← ←
48 STRAINER 1 CWB11094 ← ←
49 EXPANSION VALVE 1 CWB051016J ← ←
51 V-COIL COMPLETE 1 CWA43C2257 ← ←
52 BAG 1 CWG861078 ← ←
53 BASE BOARD - COMPLETE 1 CWG62C1162 ← ←
54 SHOCK ABSORBER (R) 1 CWG713415 ← ←
55 SHOCK ABSORBER (L) 1 CWG713416 ← ←
