o nanoe-G breakdown error

 Judgment method

• Hi-feedback voltage (at microcontroller) supplied to the nanoe-G system when nanoe-G operation is

OFF; nanoe-G breakdown error show immediately.

• It is due to indoor PCB or nanoe-G high voltage power supply damage.

• Operations except nanoe-G continue. Both Timer indicator and nanoe-G indicator blink.

 Troubleshooting method

• Press nanoe-G button or OFF/ON button to stop the operation.

• Change nanoe-G high voltage power supply or main PCB.

• When Lo-feedback voltage supplied to nanoe-G system during nanoe-G operation ON, nanoe-G

indicator and Timer indicator stop blinking.
